Epro PR6424/010-030 Eddy Current Displacement Sensor
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Eddy Current Displacement Sensor |
| Product Model | PR6424/010-030 |
| Manufacturer | EPRO / Emerson |
| Series | PR6424 Series |
| Measurement Principle | Non-contact eddy current measurement technology |
| Application | Shaft radial displacement, axial position, vibration monitoring, eccentricity, and speed/key measurement of rotating machinery |
| Sensor Diameter | 16 mm |
| Measuring Range | Static ±2.0 mm / Dynamic 0 to 1,000 μm |
| Sensitivity | 4 V/mm (101.6 mV/mil) |
| Linearity Error | ≤ ±1.5% |
| Nominal Air Gap | Approx. 2.7 mm |
| Target Material | Ferromagnetic steel (42CrMo4 standard) |
| Maximum Surface Speed | Approx. 2,500 m/s |
| Minimum Shaft Diameter | ≥80 mm |
| Cable Type | PTFE insulated cable |
| Sensor Sleeve Material | Stainless steel |
| Operating Temperature | -35°C to +180°C |
| Short-Term Temperature Limit | Up to +200°C |
| Pressure Resistance | Up to 10,000 hPa |
| Shock and Vibration Resistance | 5g at 60 Hz (25°C) |
| Long-Term Drift | <0.3% |
| Signal Converter Compatibility | EPRO CON011 / CON021 / CON041 series |
| System Compatibility | EPRO MMS 3000 / MMS 6000 machinery monitoring systems |
| Application Areas | Steam turbines, gas turbines, hydro turbines, compressors, pumps, fans, and critical rotating equipment |
| Dimensions | Approx. 52.5 mm × 16 mm (sensor body, excluding cable) |
| Weight | Approx. 0.2 kg (sensor with 1 m cable, without armor) |
FAQ
Q: What is the main function of the PR6424/010-030?
A: The PR6424/010-030 is an eddy current displacement sensor used for precise, non-contact measurement of shaft displacement, vibration, and position in rotating machinery.
Q: What type of product is the PR6424/010-030?
A: The PR6424/010-030 is classified as an Eddy Current Displacement Sensor designed for industrial machinery condition monitoring and protection applications.
Q: Which brand manufactures the PR6424/010-030?
A: The PR6424/010-030 is manufactured by EPRO / Emerson and belongs to the PR6424 series of 16 mm eddy current sensors.
Q: Where is the PR6424/010-030 commonly used?
A: It is widely used in steam turbines, gas turbines, compressors, pumps, fans, and other rotating equipment requiring continuous shaft monitoring.
Q: How does the PR6424/010-030 measure displacement?
A: The sensor uses eddy current technology to detect changes in the distance between the probe tip and the conductive shaft surface without physical contact.
Q: Does the PR6424/010-030 require a signal converter?
A: Yes. The sensor normally operates with an EPRO CON011, CON021, or CON041 signal converter to process the measurement signal.
Q: What are the advantages of the PR6424/010-030?
A: It provides high measurement accuracy, fast response, wear-free operation, stable long-term performance, and reliable operation in harsh industrial environments.
Q: What should be checked before replacing a PR6424/010-030 sensor?
A: The sensor model, thread specification, cable configuration, measuring range, installation gap, target material, and compatible signal converter should be confirmed before replacement.
Epro PR6424/010-030 Eddy Current Displacement Sensor is in stock. Please contact us for a quick quote and competitive pricing.
