Bently Nevada 9200-06-01-11-04 Two-Wire Velocity Seismoprobe Transducer
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Two-Wire Velocity Seismoprobe Transducer |
| Product Model | 9200-06-01-11-04 |
| Manufacturer | Bently Nevada |
| Series | 9200 Seismoprobe |
| Operating Principle | Moving-coil velocity sensing |
| Sensitivity | 20 mV/mm/s (500 mV/in/s), ±5% |
| Frequency Response | 4.5 to 1,000 Hz, +0/-3 dB typical |
| Calibration Load | 10 kΩ |
| Coil Resistance | 1.25 kΩ ±5% |
| Locked Coil Inductance | 125 mH typical |
| Dynamic Operating Range | 2.54 mm peak-to-peak maximum displacement |
| Amplitude Linearity | ±5% from 0.01 to 5.0 in/s at 100 Hz |
| Shock Resistance | Up to 50 g peak acceleration |
| Operating Temperature | -29°C to +121°C (-20°F to +250°F) |
| Relative Humidity | Up to 95%, non-condensing |
| Mounting Base | Isolated circular M10 × 1 |
| Connector | Top-mount configuration |
| External Power | Not required |
| Dimensions | Approx. 102 mm height × 41 mm diameter |
| Weight | Approx. 0.3 kg |
| Agency Approval | ATEX/IECEx |
| Country of Origin | USA |
FAQ
Q: What is the 9200-06-01-11-04 designed to measure?
A: It is designed to measure vibration velocity on the casing of rotating machinery. Typical applications include turbines, motors, pumps, fans, compressors, and other industrial machines.
Q: What sensing technology does this model use?
A: The 9200-06-01-11-04 uses a moving-coil velocity sensing principle. The generated electrical signal is proportional to the vibration velocity of the machine casing.
Q: What is the nominal sensitivity?
A: The nominal sensitivity is 20 mV/mm/s, equivalent to 500 mV/in/s, with a tolerance of ±5%.
Q: Does the transducer need an external power supply?
A: No. The moving-coil design is self-powered and does not require external excitation. The sensor produces an output signal as mechanical vibration moves the internal coil.
Q: What is the frequency response of the 9200-06-01-11-04?
A: The typical frequency response is 4.5 to 1,000 Hz with a +0/-3 dB tolerance. This makes the sensor suitable for a wide range of machinery vibration monitoring tasks.
Q: How is the sensor mounted?
A: This version uses an isolated circular M10 × 1 mounting base. The isolated mounting arrangement is suitable for installations where electrical isolation between the transducer and machine structure is required.
Q: What are the physical dimensions and weight?
A: The transducer is approximately 102 mm high and 41 mm in diameter, with an approximate weight of 0.3 kg. Actual dimensions may vary slightly depending on the connector arrangement.
Q: Is the 9200-06-01-11-04 suitable for hazardous-area applications?
A: Yes. The “04” agency-approval configuration is associated with ATEX/IECEx certification. The applicable certification and installation requirements should be verified against the specific equipment documentation before installation.
Bently Nevada 9200-06-01-11-04 Two-Wire Velocity Seismoprobe Transducer is in stock. Please contact us for a quick quote and competitive pricing.
