ABB Bailey IMMPI02 Product Documentation
Product Introduction
The ABB Bailey IMMPI02 is a high-performance interface module designed for industrial automation and control systems. It serves as a critical component in ABB’s Bailey INFI 90 system, facilitating communication between different modules and subsystems. This module is widely used in power generation, process control, and other industrial applications due to its reliability and robust design.
The IMMPI02 ensures seamless data exchange and integration within complex control architectures, making it an essential part of modern automation systems. Its rugged construction and advanced features make it suitable for harsh industrial environments.
Product Advantages
- High Reliability – Designed for continuous operation in demanding industrial environments.
- Seamless Integration – Compatible with the Bailey INFI 90 system, ensuring smooth communication.
- Robust Construction – Built to withstand harsh conditions, including high temperatures and vibrations.
- Easy Maintenance – Modular design allows for quick replacement and minimal downtime.
- Wide Compatibility – Supports integration with various ABB control systems and third-party devices.
- Long Service Life – High-quality components ensure extended operational lifespan.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB Bailey IMMPI02 |
| Dimensions (W x H x D) | 120 mm x 80 mm x 40 mm |
| Weight | 0.5 kg |
| Operating Voltage | 24V DC (±10%) |
| Power Consumption | 5W max |
| Communication Protocol | INFI 90 System Protocol |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Certifications | CE, UL, IEC 61000-6-2 (EMC) |
Applications
The ABB Bailey IMMPI02 is primarily used in:
- Power Plants – For control and monitoring of turbines, boilers, and generators.
- Oil & Gas – In process control systems for refineries and pipelines.
- Chemical Processing – For automation and safety systems in chemical plants.
- Water Treatment – In SCADA systems for managing filtration and distribution.
- Manufacturing – For integration into industrial automation lines.
Compatible Models
The IMMPI02 is designed to work with the following ABB Bailey modules:
- NISD02 – Network Interface Module
- NIMP01 – Processor Module
- NIDP01 – Digital Input Module
- NIAP01 – Analog Input Module
- NIRP01 – Relay Output Module
Installation Instructions
- Power Off – Ensure the system is powered down before installation.
- Mounting – Secure the module in the designated slot using the provided screws.
- Wiring – Connect the power supply (24V DC) and communication cables as per the wiring diagram.
- Configuration – Use the Bailey INFI 90 software to configure the module.
- Testing – Power on the system and verify communication with connected devices.
- Final Check – Ensure all connections are secure and the module is functioning correctly.
Recommended Related Models (Same Series)
| Model | Description | Dimensions | Weight | Voltage |
|---|---|---|---|---|
| IMMPI01 | Interface Module (Basic) | 120x80x40 mm | 0.45 kg | 24V DC |
| IMMPI03 | Enhanced Interface Module | 120x80x40 mm | 0.55 kg | 24V DC |
| IMMPI04 | High-Speed Interface Module | 120x80x40 mm | 0.6 kg | 24V DC |
| IMMPI05 | Redundant Interface Module | 120x80x40 mm | 0.65 kg | 24V DC |
| IMMPI06 | Advanced Communication Module | 120x80x40 mm | 0.7 kg | 24V DC |
| IMMPI07 | Industrial Protocol Converter | 120x80x40 mm | 0.75 kg | 24V DC |
Popular ABB Models (Other Series)
| Model | Description | Dimensions | Weight | Voltage |
|---|---|---|---|---|
| AC500 | PLC Controller | 200x150x80 mm | 1.2 kg | 24V DC / 120V AC |
| ACS880 | Industrial Drive | 300x200x150 mm | 5 kg | 380-480V AC |
| REF615 | Protection Relay | 150x100x60 mm | 1 kg | 24-48V DC |
| CP635 | HMI Panel | 250x200x50 mm | 2 kg | 24V DC |
| DSQC652 | Robot Controller | 180x120x70 mm | 1.5 kg | 24V DC |
| S800 I/O | Remote I/O Module | 100x80x30 mm | 0.4 kg | 24V DC |
| UniGear ZS1 | Switchgear | 600x800x2200 mm | 300 kg | 400V AC |
| Tmax XT | Circuit Breaker | 150x100x80 mm | 2.5 kg | 230V AC |
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the ABB Bailey IMMPI02?
A1: The IMMPI02 serves as an interface module for the Bailey INFI 90 system, enabling communication between different control modules.
Q2: Can the IMMPI02 operate in high-temperature environments?
A2: Yes, it is designed to operate in temperatures ranging from -20°C to +70°C.
Q3: What power supply is required for the IMMPI02?
A3: It requires a 24V DC power supply with a ±10% tolerance.
Q4: Is the IMMPI02 compatible with third-party systems?
A4: It is primarily designed for ABB’s Bailey INFI 90 system but can interface with third-party devices using appropriate converters.
Q5: How do I troubleshoot communication issues with the IMMPI02?
A5: Check power supply, wiring connections, and ensure proper configuration in the INFI 90 software.
Q6: What is the expected lifespan of the IMMPI02?
A6: With proper maintenance, the module can operate reliably for over 10 years in industrial environments.
ABB Bailey IMMPI02 Multi-Function Processor Interface Quality Selection is in stock. Please contact us for a quick quote and competitive pricing.
