ABB Bailey ITCTU05 18231161 B Terminal Unit
Product Overview
The ABB Bailey ITCTU05 18231161 B Terminal Unit is a highly reliable input/output terminal unit designed for use in Bailey Infi 90 control systems. This module provides efficient and secure communication between the controller and field devices. The ITCTU05 is equipped with advanced features to handle critical control functions in industrial automation systems, ensuring that the real-time data exchange between the controller and field instruments is fast, accurate, and fault-tolerant.
The ITCTU05 Terminal Unit supports multiple signal types (analog, digital, and discrete) and is capable of seamless integration into large-scale, complex systems. With its modular design, it allows for easy expansion, replacement, and maintenance, making it a flexible solution for industrial automation applications.
Key Features
-
Versatile I/O Interface: Supports analog, digital, and discrete I/O signals for a wide range of field devices, including sensors, actuators, and control devices.
-
Flexible Communication: Provides reliable communication with Bailey Infi 90 controllers via fieldbus or backplane connections.
-
Modular Design: Offers easy expandability and maintenance, allowing for the addition or replacement of units without disrupting system operations.
-
Enhanced Diagnostics: Built-in diagnostic capabilities ensure quick identification of issues, improving system uptime and minimizing downtime.
-
Real-Time Data Handling: Delivers high-speed data transfer, ensuring that the control system can react to changing process conditions without delays.
-
Rugged and Reliable: Designed for industrial environments, the unit is built to handle demanding conditions and ensure continuous operation.
-
Compliance: Meets industry standards for safety and reliability, ensuring its suitability for critical applications.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 220 x 220 x 140 mm |
| Weight | 0.4 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Voltage Range | 24 V DC |
| Power Consumption | Approx. 6 W |
| Communication | Fieldbus or Backplane Communication |
| Output Rating | 24 V DC (for digital outputs) |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | -40°C to +70°C |
| Storage Temp | -40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Bailey Infi 90 Control Systems |
| Communication Protocol | Fieldbus or Backplane |
| Software Support | ABB Infi 90 Configuration Tools |
Industry Applications
-
Oil & Gas: Provides crucial I/O control for automation systems in offshore platforms, refineries, and pipelines.
-
Power Generation: Used in power plants to control and monitor boilers, turbines, and generators for efficient operation and safety.
-
Chemical Processing: Supports real-time process control and monitoring of critical chemical production systems.
-
Water Treatment: Used in wastewater treatment and water purification plants for managing field devices such as pumps, valves, and flow meters.
-
Manufacturing: Facilitates automated production lines and ensures accurate process control in manufacturing plants.
The ABB Bailey ITCTU05 18231161 B Terminal Unit is an essential component for Bailey Infi 90 control systems, providing reliable I/O processing and seamless communication with field devices. With its modular design, enhanced diagnostics, and real-time data handling, this terminal unit is an ideal solution for industries such as oil & gas, power generation, chemical processing, and manufacturing. Its robustness and flexibility make it a key component in maintaining efficient and safe automation systems.
