Technical Specifications
| Parameter | Specification |
|---|---|
| Ordering Number | 1MRK002246-BB |
| Manufacturer | ABB |
| Product Type | Power Supply Board |
| Board Type | Industrial Power Supply Board |
| Main Function | Provides stable and regulated power for compatible industrial automation and control equipment |
| Input Voltage | 100–240 VAC |
| Output Voltage | 24 VDC |
| Output Current | Up to 40 A |
| Efficiency | Up to 90% |
| Power Factor Correction | Active PFC |
| Protection Functions | Overload, short-circuit, and overvoltage protection |
| Monitoring | Voltage, current, and temperature monitoring |
| Remote Control | Supports power supply control and output adjustment functions |
| Typical Application | Industrial automation, control cabinets, and critical control systems |
| Installation | Control cabinet / industrial automation equipment |
| Operating Environment | Industrial automation and control applications |
| Maintenance | Power input/output checks, terminal inspection, alarm diagnosis, and board replacement |
| Dimensions | 310 × 250 × 30 mm |
| Weight | 0.5 kg |
FAQ
Q1: What is the main function of the ABB 1MRK002246-BB Power Supply Board?
The 1MRK002246-BB is a power supply board designed to provide stable DC power for compatible industrial automation and control equipment. It converts the AC input into a regulated DC output that can be used by control electronics and other connected system components.
Q2: What input and output voltage does the 1MRK002246-BB support?
The board is specified for a 100–240 VAC input and a 24 VDC output. The wide AC input range allows it to be used with different industrial power systems while maintaining a suitable DC supply for connected automation equipment.
Q3: What is the maximum output current of the 1MRK002246-BB?
The specified output current is up to 40 A. When selecting or replacing the board, the expected system load should be checked to ensure that the connected equipment does not exceed the available power capacity.
Q4: What protection functions are available on the 1MRK002246-BB?
The power supply board includes protection functions for conditions such as overload, short circuit, and overvoltage. These functions help protect the power supply and connected equipment when abnormal electrical conditions occur.
Q5: What should be checked if the 1MRK002246-BB has no 24 VDC output?
First check whether the AC input is present and within the specified 100–240 VAC range. Then inspect the input wiring, terminals, fuses or protective devices, and output connections. If the input is correct but the 24 VDC output is absent, the board’s internal power conversion and protection circuits should be investigated.
Q6: What can cause the 1MRK002246-BB to shut down under load?
An excessive load, short circuit, unstable AC input, poor electrical connections, or overheating can cause the power supply to enter a protection state. The connected load should be isolated and checked before repeatedly restarting the power supply. If the problem occurs even with a normal load, further inspection of the board is recommended.
Q7: What should be checked before replacing the 1MRK002246-BB?
Confirm the complete ordering number 1MRK002246-BB, the required input voltage, 24 VDC output requirement, output current demand, connector arrangement, and compatibility with the host system. The existing wiring should be documented before removal, and power should be isolated before replacing the board unless the applicable equipment documentation specifically permits live replacement.
Q8: How should the 1MRK002246-BB be maintained?
Routine maintenance should include checking AC input stability, DC output voltage, terminal tightness, connectors, protective devices, and system alarms. The board should also be checked for signs of overheating or abnormal operation. If voltage fluctuations or repeated protection trips occur, inspect the complete power supply circuit and connected load rather than repeatedly resetting the board.
ABB 1MRK 002246-BB Power Supply Board is in stock. Please contact us for a quick quote and competitive pricing.
