ABB 3BHB023302R0001 Control Unit Module
Product Overview
The ABB 3BHB023302R0001 is a high-performance control unit module designed for ABB’s AC 800M programmable automation controller series. This module serves as a central processing unit in industrial automation systems, providing reliable control execution and data processing capabilities for complex industrial processes. It is engineered to operate in demanding industrial environments with enhanced reliability and deterministic performance, ensuring precise control in critical applications.
_
Main Features
• Powerful 32-bit RISC processor for high-speed control execution
• Integrated redundancy support for fault-tolerant system operation
• Extended memory capacity for complex application programs
• Multiple communication interfaces including Ethernet and serial protocols
• Built-in self-diagnostic functions for predictive maintenance
• Hot-swappable capability for minimal system downtime
• Compliance with international standards for industrial safety and EMC
• Seamless integration with ABB’s System 800xA platform
_
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 233 × 130 × 40 mm |
| Weight | 0.68 kg |
| _ |
General Information
| Item | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | 3BHB023302R0001 |
| Product Type | Control Unit Module |
| Series | AC 800M |
| Mounting | Backplane mounting |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| _ |
Electrical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24V DC ±10% |
| Power Consumption | 10W (typical) |
| Processor Type | 32-bit RISC |
| Memory | 128 MB DRAM, 32 MB Flash |
| Communication Ports | 2× Ethernet, 1× RS-232, 1× RS-485 |
| Isolation Voltage | 1500V AC |
| Redundancy Support | Yes |
| _ |
Environmental Specifications
| Item | Specification |
|---|---|
| Humidity Range | 5-95% RH (non-condensing) |
| Vibration Resistance | 5-200Hz, 2G (IEC 60068-2-6) |
| Shock Resistance | 15G, 11ms (IEC 60068-2-27) |
| Protection Class | IP20 (when installed in enclosure) |
| EMC Compliance | EN 61326, EN 61000-6-2, EN 61000-6-4 |
| _ |
Industry Applications
The ABB 3BHB023302R0001 is widely used in:
• Power Generation: Turbine control, boiler automation, and grid management systems
• Oil & Gas: Pipeline monitoring, refining processes, and offshore platform control
• Chemical Processing: Reactor control, batch processing, and safety instrumented systems
• Water Treatment: Pump control, filtration systems, and distribution network management
• Pharmaceutical: Process automation and environmental control systems
• Manufacturing: Production line automation and quality control systems
• Marine: vessel control systems and offshore applications
ABB 3BHB023302R0001 Control Unit Module is in stock. Please contact us for a quick quote and competitive pricing.
