ABB 5SGX0845F0001 3BHL000385P0101 IGCT Modules
1. Product Overview
The ABB 5SGX0845F0001 3BHL000385P0101 IGCT (Integrated Gate-Commutated Thyristor) module is an advanced power electronic switch designed for high-current and high-power applications. It is widely used in high-voltage direct current (HVDC) transmission, medium-voltage drives (MV Drives), flexible AC transmission systems (FACTS), and motor drive systems. This module combines the advantages of thyristors and gate turn-off thyristors (GTOs), providing high current capacity, low conduction losses, and fast turn-off capabilities. It significantly improves system efficiency and response speed.
The 5SGX0845F0001 3BHL000385P0101 IGCT module is built with ABB’s leading semiconductor technology and innovative packaging design, ensuring excellent electrical performance and long-term reliability. It is the ideal choice for demanding industrial and power applications.
2. Key Features
-
High Voltage Endurance: The module supports high voltage operation, ensuring stable and reliable system performance.
-
Low Conduction Loss: The optimized design reduces the energy loss during current conduction, improving overall system efficiency.
-
Fast Turn-Off Characteristics: With short turn-off time, it is suitable for high-frequency and high-speed control applications.
-
High Current Handling: The module can handle currents up to several thousand amperes, making it ideal for high-power density applications.
-
Integrated Gate Drive: The built-in gate drive circuit simplifies peripheral circuit design, enhancing system reliability.
-
Efficient Heat Dissipation: The optimized thermal management design ensures stable temperature even during high-power operation, extending the module’s service life.
3. Technical Specifications
3.1 Dimensions and Weight
| Item | Value |
|---|---|
| Diameter | 130 x 85 x 65 mm |
| Weight | 1.2 kg |
3.2 General Information
| Item | Value |
|---|---|
| Model | 5SGX0845F0001 3BHL000385P0101 |
| Manufacturer | ABB |
| Component Type | IGCT (Integrated Gate-Commutated Thyristor) |
| Applications | HVDC, MV Drives, FACTS, Motor Drives |
| Insulation Voltage | Up to 6500V |
3.3 Electrical Performance
| Item | Value |
|---|---|
| Rated Voltage | 4500V |
| Rated Current | 2500A |
| On-State Voltage Drop | ≤ 2.5V |
| Turn-Off Time | ≤ 25 μs |
| Gate Trigger Current | 20A |
| Turn-Off Loss | Low-loss design for enhanced efficiency |
| Overload Protection | Yes |
4. Industry Applications
The ABB 5SGX0845F0001 3BHL000385P0101 IGCT module is widely used in the following applications:
-
High-Voltage Direct Current (HVDC) Transmission: Used in power systems for commutation, improving power transmission efficiency and stability.
-
Medium-Voltage Drives (MV Drives): Provides efficient power conversion for medium-voltage motor drive systems, widely used in industrial automation.
-
Flexible AC Transmission Systems (FACTS): Enhances the stability and flexibility of power systems, optimizing grid operation.
-
Railway Traction: Applied in railway power drive systems, providing efficient power conversion and stable drive control for trains.
-
Renewable Energy Systems: Used in wind and solar power systems to facilitate power conversion and improve the utilization of renewable energy.
The ABB 5SGX0845F0001 3BHL000385P0101 IGCT module is a key component in modern high-power electrical systems, providing superior electrical characteristics and long-term reliability in demanding applications.
ABB 5SGX0845F0001 3BHL000385P0101 IGCT Modules is in stock. Please contact us for a quick quote and competitive pricing.
