ABB 5SHX0660F0002 3BHE022333R0101 IGCT Module
Product Overview
The ABB 5SHX0660F0002 3BHE022333R0101 is a high-performance Integrated Gate-Commutated Thyristor (IGCT) module, engineered for advanced medium-voltage power electronics applications. Designed to handle high current and voltage levels, this IGCT module is ideal for use in demanding industrial systems such as traction converters, medium-voltage drives, and power grid systems.
This device combines the robust characteristics of thyristors with the fast-switching capability of gate turn-off devices, offering superior efficiency, reliability, and thermal performance. ABB’s expertise in semiconductor design ensures that the 5SHX0660F0002 module operates with minimal losses and extended service life even under extreme electrical and thermal conditions.
Key Features
-
High Voltage and Current Ratings: Suitable for demanding power electronic applications.
-
Integrated Design: Combines the gate unit and thyristor for enhanced switching performance.
-
High Switching Frequency: Allows efficient operation in applications requiring fast response.
-
Robust Construction: Engineered to withstand high thermal and electrical stress.
-
Long Service Life: Optimized for durability and reduced maintenance.
-
Low Conduction and Switching Losses: Improves overall energy efficiency.
-
Reliable Operation: Designed for use in harsh industrial and traction environments.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 190 mm x 140 mm x 38 mm |
| Weight | 1.2 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Part Number | 5SHX0660F0002 |
| ABB Ordering Code | 3BHE022333R0101 |
| Device Type | IGCT (Integrated Gate-Commutated Thyristor) |
| Voltage Rating (V<sub>DRM</sub>) | 4500 V |
| Current Rating (I<sub>TG</sub>) | 4000 A |
| Turn-Off Time | < 1500 ns |
| Gate Trigger Current | ≤ 10 A |
| Peak Gate Voltage | ±20 V |
3.3 Thermal & Environmental Ratings
| Item | Specification |
|---|---|
| Operating Temperature | -40°C to +125°C |
| Storage Temperature | -40°C to +125°C |
| Maximum Junction Temp. | 125°C |
| Isolation Voltage | ≥ 6000 V |
| Cooling Method | Forced Air or Liquid Cooling (depending on system) |
Industry Applications
-
Medium Voltage Drives: Enhances control and efficiency in high-power motor drive systems.
-
Traction Systems: Used in railway and electric locomotive systems for high-reliability switching.
-
HVDC Systems: Supports high-voltage DC power transmission for improved grid efficiency.
-
Static VAR Compensators: Provides voltage regulation and power factor correction.
-
Renewable Energy Converters: Integrates with wind and solar inverter systems requiring robust switching.
-
Industrial Power Supplies: Enables energy-efficient conversion in heavy industrial equipment.
The ABB 5SHX0660F0002 3BHE022333R0101 IGCT Module represents a reliable and efficient solution for high-power electronics, delivering superior switching performance, extended durability, and broad application flexibility. It is a preferred choice for engineers designing systems that demand robust performance under challenging conditions.
