ABB 5SHX1060H0003 3BHB020538R0001 IGCT Module
Product Overview
The ABB 5SHX1060H0003 3BHB020538R0001 IGCT Module is a high-capacity Integrated Gate-Commutated Thyristor (IGCT) designed for use in demanding high-power industrial and traction applications. This module delivers efficient and reliable switching performance at high voltage and current ratings, making it ideal for use in medium-voltage drives, static VAR compensators, and high-voltage DC (HVDC) transmission systems.
Engineered with ABB’s advanced semiconductor technology, the 5SHX1060H0003 combines rugged construction with fast switching capability and low power losses. Its integrated gate unit design allows for simplified assembly, excellent thermal management, and long operational life in harsh electrical environments.
Key Features
-
High Current and Voltage Capacity: Designed to operate at up to 6000 A and 4500 V, suitable for high-power systems.
-
Integrated Gate Unit Design: Enhances gate control precision and minimizes switching losses.
-
Low Switching and Conduction Losses: Ensures high efficiency in continuous operation.
-
Fast Turn-Off Time: Enables rapid switching in real-time control applications.
-
High Thermal Stability: Built for continuous operation in thermally demanding conditions.
-
Robust and Reliable: Suitable for use in harsh industrial and railway traction environments.
-
Long Service Life: ABB’s quality and reliability standards ensure durability and low maintenance.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 190 mm x 140 mm x 38 mm |
| Weight | 1.2 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Model Number | 5SHX1060H0003 |
| Ordering Code | 3BHB020538R0001 |
| Device Type | IGCT |
| Peak Repetitive Off-State Voltage (V<sub>DRM</sub>) | 4500 V |
| Maximum Continuous Current (I<sub>TG</sub>) | 6000 A |
| Gate Trigger Current | ≤ 12 A |
| Peak Gate Voltage | ±20 V |
| Turn-Off Time | < 1500 ns |
| Isolation Voltage | ≥ 6000 V |
3.3 Thermal & Environmental Ratings
| Item | Specification |
|---|---|
| Operating Temperature | -40°C to +125°C |
| Storage Temperature | -40°C to +125°C |
| Maximum Junction Temperature | 125°C |
| Cooling Method | Forced air or liquid (system dependent) |
Industry Applications
-
Medium-Voltage Motor Drives: Enhances performance and energy efficiency in high-power motor control systems.
-
Rail Traction Converters: Provides robust and reliable switching for electric locomotives and light rail.
-
HVDC Systems: Ideal for high-voltage direct current transmission applications.
-
Static VAR Compensators (SVC): Enables voltage stabilization and reactive power compensation in large power grids.
-
Renewable Energy Converters: Supports high-efficiency energy conversion in solar and wind power systems.
-
Industrial Power Control: Facilitates power switching in heavy-duty industrial automation and process equipment.
The ABB 5SHX1060H0003 3BHB020538R0001 IGCT Module is a dependable and high-performance component for applications requiring robust power switching and long-term reliability. It is engineered for precision, efficiency, and longevity in the most demanding industrial and electrical grid environments.
ABB 5SHX1060H0003 3BHB020538R0001 IGCT Modules is in stock. Please contact us for a quick quote and competitive pricing.
