ABB 5SHX2645L0004 3BHL000389P0104 IGCT Module
Product Overview
The ABB 5SHX2645L0004 (Part Number: 3BHL000389P0104) is a high-performance Integrated Gate-Commutated Thyristor (IGCT) module engineered for use in high-voltage and high-power industrial applications. As a robust hybrid between traditional thyristors and IGBT technology, it provides fast switching capabilities, high current handling, and long-term reliability. This IGCT module is particularly suited for use in HVDC systems, high-power motor drives, and power converters requiring rugged and efficient switching components.
Its compact and modular design simplifies installation and maintenance, while its excellent thermal and electrical characteristics support its use in demanding environments across various sectors.
Key Features
-
High Voltage and Current Capability: Rated for voltages up to 4500V and currents up to 6000A, suitable for high-power electronic applications.
-
Fast Switching Performance: Achieves switching frequencies up to 2kHz with low conduction losses and turn-off times as short as 10μs.
-
Rugged Construction: Designed to withstand harsh industrial conditions including wide operating temperatures and high EMI environments.
-
Modular Design: Allows for easy integration into inverter and converter systems with minimal space requirements.
-
Reverse Conducting Capability: Features integrated reverse conduction, improving system design flexibility.
-
High Reliability: Proven operational durability in critical applications such as energy transmission and heavy industry.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 85 x 50 x 35mm |
| Weight | 0.2 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | 5SHX2645L0004 |
| Part Number | 3BHL000389P0104 |
| Manufacturer | ABB |
| Mounting Method | Modular |
| Country of Origin | Sweden |
| Operating Temp | -40°C to +125°C |
3.3 Performance Characteristics
| Item | Specification |
|---|---|
| Max Continuous Current | 6000 A |
| Blocking Voltage | Up to 4500 V (max 12 kV peak) |
| Switching Frequency | Up to 2 kHz |
| Conduction Loss | 1.5 mΩ |
| Turn-Off Time | Approx. 10 μs |
| Electrical Isolation | Full isolation from gate unit |
Industry Applications
-
HVDC Power Transmission: Used in high-voltage direct current systems for energy transmission over long distances.
-
Heavy Industry Motor Drives: Drives large motors in steel mills, mining, and heavy manufacturing sectors.
-
Renewable Energy Systems: Applied in wind and solar power converters for grid integration and control.
-
Traction Systems: Integrated into propulsion systems of electric trains, subways, and trams for efficient operation.
-
Marine Propulsion: Provides reliable power control in ships and offshore platforms.
The ABB 5SHX2645L0004 3BHL000389P0104 IGCT Module is a critical component in modern high-voltage power systems, offering a powerful mix of durability, efficiency, and performance. Its proven technology and robust design make it indispensable in industrial and utility-scale power electronics.
ABB 5SHX2645L0004 3BHL000389P0104 IGCT Module is in stock. Please contact us for a quick quote and competitive pricing.
