ABB 5SHY5055L0002 3BHB026114R0001 IGCT Modules
1. Product Overview
The ABB 5SHY5055L0002 3BHB026114R0001 IGCT (Integrated Gate-Commutated Thyristor) module is an advanced power electronic switch designed for high-current and high-power conversion systems. As an integrated gate commutated thyristor, this module combines the benefits of both thyristors and gate turn-off thyristors (GTOs), providing low conduction losses, high switching speed, and excellent reliability. It is widely used in high-voltage direct current (HVDC) transmission, medium-voltage drives (MV Drives), flexible AC transmission systems (FACTS), power transmission and distribution systems, and other power conversion applications.
This IGCT module features ABB’s state-of-the-art semiconductor technology and optimized packaging design, offering high current handling and stable performance in high voltage environments. Its exceptional electrical performance and efficient heat dissipation ensure stability and efficiency even under prolonged high-power load conditions, making it an ideal component in modern power electronic systems.
2. Key Features
-
High Voltage Endurance: The module supports high voltage operations, ensuring stable system performance under high-load conditions.
-
Low Conduction Loss: The optimized design significantly reduces conduction losses, enhancing overall system efficiency.
-
Fast Turn-Off Characteristics: The module features a fast turn-off time, making it suitable for high-frequency switching and frequent control applications.
-
High Current Handling: The module can handle high currents, meeting the demands of high-power power conversion systems.
-
Integrated Gate Drive: The built-in gate drive circuit simplifies peripheral circuit design, increasing system reliability.
-
Efficient Heat Dissipation: Equipped with an efficient thermal management system, the module ensures stability during high-power operations and prolongs service life.
3. Technical Specifications
3.1 Dimensions and Weight
| Item | Value |
|---|---|
| Diameter | 500mm x 300mm x 200mm |
| Weight | 1.5 kg |
3.2 General Information
| Item | Value |
|---|---|
| Model | 5SHY5055L0002 3BHB026114R0001 |
| Manufacturer | ABB |
| Component Type | IGCT (Integrated Gate-Commutated Thyristor) |
| Applications | HVDC, MV Drives, FACTS, Motor Drives |
| Insulation Voltage | Up to 8000V |
3.3 Electrical Performance
| Item | Value |
|---|---|
| Rated Voltage | 6000V |
| Rated Current | 5000A |
| On-State Voltage Drop | ≤ 2.4V |
| Turn-Off Time | ≤ 25 μs |
| Gate Trigger Current | 35A |
| Turn-Off Loss | Low-loss design for enhanced efficiency |
| Overload Protection | Yes |
4. Industry Applications
The ABB 5SHY5055L0002 3BHB026114R0001 IGCT module is used in a wide range of applications, particularly in high-current and high-power conversion power systems:
-
High-Voltage Direct Current (HVDC) Transmission: Used for efficient power transmission, optimizing long-distance transmission and ensuring system stability.
-
Medium-Voltage Drives (MV Drives): Applied in medium-voltage motor drive systems, providing stable and efficient power conversion in industrial automation applications.
-
Flexible AC Transmission Systems (FACTS): Enhances system stability, flexibility, and controllability, optimizing power grid operation.
-
Railway Traction: Used in railway power drive systems, improving energy efficiency and system stability for frequent operation.
-
Wind and Solar Power: Optimizes power conversion in renewable energy systems such as wind and solar power, enhancing energy efficiency.
The ABB 5SHY5055L0002 3BHB026114R0001 IGCT module is an essential component for modern high-power electrical systems, offering exceptional electrical performance, high reliability, and stability in demanding applications.
