ABB 5SXE12-0184 GV C736 CE101 3BHE039203R0101 IGCT (Inductively Controlled Thyristor Module)
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Name | IGCT (Inductively Controlled Thyristor Module) |
| Commercial Code | 5SXE12-0184 |
| Model | GV C736 CE101 |
| Part Number | 3BHE039203R0101 |
| Device Type | Inductively Controlled Thyristor (IGCT) module |
| Application | Medium-voltage industrial drives and power conversion systems |
| Main Function | High-power switching and controlled energy conversion |
| Rated Voltage Class | Suitable for medium-voltage applications (system dependent) |
| Rated Current | High-current capability for industrial loads |
| Switching Performance | Fast turn-on and turn-off with low switching losses |
| Gate Control | Integrated inductive gate control interface |
| Cooling Method | Forced air or liquid cooling integration |
| Protection Features | Overcurrent, overvoltage, and thermal supervision (system dependent) |
| Isolation | Electrical isolation between gate unit and power circuit |
| Mounting Type | Mechanical clamping within power assembly |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Dimensions | 150 × 140 × 40 mm |
| Weight | 0.5 kg |
FAQ
Q1: What is the primary function of the 5SXE12-0184 IGCT module?
A1: It provides high-power switching control in medium-voltage drive and power conversion systems.
Q2: What distinguishes an IGCT from a conventional thyristor?
A2: An IGCT integrates inductive gate control for faster turn-off capability and improved switching performance compared to traditional thyristors.
Q3: In which applications is this module typically used?
A3: It is commonly used in medium-voltage motor drives, industrial inverters, and high-power conversion systems.
Q4: How is the device controlled?
A4: It operates with a dedicated gate drive unit that provides inductive gate current control for precise switching.
Q5: What protection mechanisms are associated with this module?
A5: System-level protection typically includes overcurrent detection, overvoltage limitation, and thermal monitoring.
Q6: What cooling arrangements are required?
A6: The module is designed to operate with integrated forced-air or liquid cooling systems in high-power assemblies.
Q7: Does the module provide electrical isolation?
A7: Yes, isolation is maintained between the gate control interface and the high-voltage power circuit.
Q8: What installation practices are recommended?
A8: Ensure proper mechanical clamping, correct busbar alignment, adequate cooling interface, and compliance with medium-voltage safety procedures.
ABB 5SXE12-0184 GV C736 CE101 3BHE039203R0101 IGCT (Inductively Controlled Thyristor Module) is in stock. Please contact us for a quick quote and competitive pricing.
