ABB 70BK03C-E HESG447440R0001 Bus Coupling Module
Product Overview
The ABB 70BK03C-E HESG447440R0001 Bus Coupling Module is an advanced communication interface designed for industrial automation systems, enabling seamless data transfer and integration between various control systems and devices. As part of ABB’s modular and scalable system architecture, the 70BK03C-E ensures high performance and reliability in connecting different bus systems within automated plants. This module supports multiple communication protocols, offering flexibility in system integration for complex industrial applications.
With its robust design and compatibility with ABB’s automation systems, the Bus Coupling Module is essential for ensuring stable and efficient communication across plant-wide networks.
Key Features
-
Multi-Protocol Support – Compatible with a range of industrial communication protocols for flexible integration
-
Reliable Data Transfer – Ensures seamless data exchange between controllers, I/O systems, and field devices
-
Modular Design – Easily integrates into existing automation setups and can be expanded as required
-
Robust Construction – Built to withstand the demanding conditions of industrial environments, ensuring long-term durability
-
Enhanced Diagnostics – Provides real-time diagnostic data to ensure optimal performance and quick fault detection
-
Flexible System Integration – Supports easy interfacing with other ABB products, ensuring smooth communication and operation within the system
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 250 × 170 × 157.4 mm |
| Weight | 0.447 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24 VDC (nominal) |
| Power Consumption | 5 W (max) |
| Bus System Support | Modbus, Profibus, CANopen, and other industrial protocols (depending on configuration) |
| Connection Type | Screw terminal connections |
| Current Rating | 2 A (per channel) |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Vibration Resistance | IEC 60068-2-6 compliant |
| Protection Rating | IP20 (module is suitable for installation in control cabinets) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Communication Protocol | Modbus, Profibus, CANopen, Ethernet (depending on configuration) |
| I/O Integration | Compatible with ABB’s control and automation systems like 800xA, S800, and more |
| Expansion Capabilities | Supports additional I/O modules and network interfaces as required |
Industry Applications
-
Manufacturing – Facilitates communication between various devices and control systems in automated factories
-
Energy and Utilities – Ensures stable and continuous data transfer between power generation, transmission, and distribution systems
-
Oil & Gas – Manages the integration of field devices and controllers for real-time monitoring and control in remote installations
-
Building Automation – Provides seamless connectivity for HVAC, lighting, security, and other automation systems within buildings
-
Process Industries – Enables system integration for process control systems, ensuring reliable communication across various control devices
The ABB 70BK03C-E HESG447440R0001 Bus Coupling Module offers a highly reliable and flexible solution for connecting different industrial automation systems. Its robust construction, support for multiple communication protocols, and compatibility with ABB’s range of products make it an essential component in ensuring smooth and efficient plant-wide communication.
