ABB CI615 3BHT300024R1 Bus Coupler
Product Overview
The ABB CI615 3BHT300024R1 Bus Coupler is a critical communication interface module used in ABB’s AC 800M control system architecture. It serves as a bridge between the AC 800M controller and field I/O units, enabling the seamless transmission of data via PROFIBUS DP—a widely adopted industrial fieldbus protocol. The CI615 facilitates real-time communication between the control system and a wide range of field devices, allowing for high-speed data exchange, efficient process control, and simplified system architecture.
Designed for high-performance automation applications, the CI615 ensures stable and reliable communication in demanding industrial environments. It provides powerful diagnostics capabilities and is engineered to support scalable and modular control solutions across industries including power generation, oil & gas, chemicals, and manufacturing.
Key Features
-
PROFIBUS DP Support – Enables robust and fast communication between the controller and field I/O devices via PROFIBUS DP protocol
-
High-Speed Data Transfer – Ensures rapid and deterministic data exchange for time-critical automation tasks
-
Modular Architecture – Seamlessly integrates into ABB’s AC 800M control system for scalable and flexible configurations
-
Robust Industrial Design – Built to operate reliably in harsh industrial conditions with strong EMC immunity
-
Advanced Diagnostics – Built-in diagnostics functions provide clear fault detection and simplified maintenance
-
Hot-Swap Capability – Supports module replacement without shutting down the system, reducing downtime
-
Flexible Field Integration – Compatible with a wide range of PROFIBUS DP field devices including sensors, actuators, and intelligent instruments
-
System Redundancy Support – Facilitates redundant system setups to enhance reliability and operational availability
-
Compact and Space-Saving – Designed for efficient panel or cabinet installation, minimizing footprint
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 252 x 273 x 40 mm |
| Weight | 1.2 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24 VDC (via system backplane) |
| Power Consumption | Approx. 2 W |
| Fieldbus Type | PROFIBUS DP |
| Max Baud Rate | 12 Mbps |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +55°C |
| Storage Temp | -40°C to +70°C |
| Humidity | 5%–95% RH (non-condensing) |
| Protection | IP20 (when installed in enclosure) |
| EMC Compliance | IEC 61000-6-2, IEC 61000-6-4 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | ABB AC 800M Control System |
| Communication | PROFIBUS DP master interface |
| Compatible Units | S800 I/O, PROFIBUS-compliant field devices |
Industry Applications
-
Power Generation – Enables real-time control and monitoring of turbines, switchgear, and plant auxiliaries in power plants
-
Oil & Gas – Provides robust communication with field instruments in drilling platforms, refineries, and pipelines
-
Chemical Industry – Supports integration with smart transmitters and actuators for safe and efficient chemical processing
-
Manufacturing Automation – Connects factory-floor devices for synchronized operation and optimized production workflows
-
Pulp & Paper – Facilitates field-level integration in complex paper mill automation systems for improved quality and reliability
The ABB CI615 3BHT300024R1 Bus Coupler is a high-performance, field-proven communication module that strengthens the reliability and scalability of ABB control systems. Its compatibility with PROFIBUS DP, robust industrial design, and ease of integration make it a preferred choice for modern process automation needs.
ABB CI615 3BHT300024R1 Bus Coupler is in stock. Please contact us for a quick quote and competitive pricing.
