ABB DATX100 3ASC25H208 Pulse Transformer Board
Product Overview
The ABB DATX100 3ASC25H208 Pulse Transformer Board is a critical component designed for pulse transformer applications in high-performance industrial systems. This board provides signal isolation and power transmission for various control and monitoring systems in industries such as automation, process control, and power distribution. The DATX100 is designed for precision in signal transfer and is essential for protecting sensitive circuits by preventing high-voltage surges from reaching the connected electronics.
With its compact design and high-efficiency performance, the ABB DATX100 is ideal for pulse signal transmission in switching equipment, motor control systems, and sophisticated power electronics that require isolated power for enhanced signal integrity and system safety.
Key Features
-
Pulse Signal Isolation: Efficiently isolates pulse signals from high-voltage systems to protect sensitive control and monitoring equipment.
-
High Precision: Ensures accurate and reliable pulse signal transmission, crucial for system performance and stability.
-
Compact Design: The module features a small footprint, making it suitable for tight spaces in control panels or electronic cabinets.
-
Durability: Built to withstand harsh industrial environments with high levels of electrical noise, ensuring reliable long-term operation.
-
High Efficiency: Provides low loss and high efficiency in power transfer, ensuring that energy is transmitted effectively with minimal loss.
-
Broad Compatibility: Compatible with a wide range of ABB control systems and automation solutions for seamless integration into existing setups.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 215 x 200 x 35 mm |
| Weight | 1.06 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Input Voltage | 24 V DC (Nominal) |
| Output Voltage | Dependent on transformer design |
| Power Rating | 15 W maximum |
| Pulse Frequency | Up to 10 kHz |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | -20°C to +85°C |
| Storage Temp | -40°C to +100°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible Systems | ABB automation systems, power control systems, motor drives |
| Mounting Type | PCB Mountable |
| Connection Type | Soldered terminals |
Industry Applications
-
Motor Control: Essential for controlling pulse signals in AC and DC motor drives, ensuring precise operation and protection.
-
Power Distribution: Used in power distribution systems to manage pulse signals in high-voltage equipment, maintaining signal integrity and system safety.
-
Signal Isolation: Ideal for isolating pulse signals in control and monitoring systems, especially in industrial automation and power electronics.
-
Renewable Energy: Utilized in wind turbines and solar power systems, where accurate signal transmission is critical for power regulation and monitoring.
-
Switching Equipment: Suitable for integration into switchgear and circuit protection equipment for improved signal isolation and protection.
The ABB DATX100 3ASC25H208 Pulse Transformer Board is an indispensable component for ensuring safe, precise, and efficient pulse signal transmission in industrial power control and automation systems. Its compact design, high efficiency, and excellent durability make it an essential part of any advanced control system requiring isolated power. Its ability to isolate sensitive circuits from high-voltage spikes ensures reliable operation and longevity, making it ideal for a wide range of industries where signal integrity and safety are paramount.
