ABB DATX131 3ASC25H215 Voltage Divider Board
Product Overview
The ABB DATX131 3ASC25H215 Voltage Divider Board is a high-performance component designed for accurate voltage measurement and signal conditioning in industrial automation systems. This voltage divider board is used to scale down high voltages to lower, measurable levels, ensuring safe and precise voltage monitoring for a wide range of control and monitoring applications. The DATX131 board is engineered for use in critical industrial environments, offering robust performance and high reliability. It integrates seamlessly with ABB’s automation and control systems, providing essential voltage data for machinery health monitoring and process control.
Key Features
-
Accurate Voltage Division – Enables precise scaling of high voltages to lower, measurable levels for safe monitoring and control
-
High-Voltage Compatibility – Capable of handling high-voltage inputs, making it suitable for a wide range of industrial applications
-
Signal Conditioning – Provides effective signal conditioning to ensure accurate readings for downstream control systems
-
Durable Construction – Built to withstand harsh industrial environments, ensuring long-term reliability and performance
-
Compact Design – Space-efficient design for easy installation within control cabinets or field-mounted systems
-
Seamless Integration – Designed to work seamlessly with ABB automation systems and industrial control networks, offering enhanced system efficiency
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 140 x 100 x 40 mm |
| Weight | 0.6 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Input Voltage | 500 V AC (max) |
| Output Voltage | 24 V DC (standard) |
| Input Impedance | 10 MΩ |
| Output Impedance | 1 kΩ |
| Accuracy | ±0.5% of full scale |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration | Up to 5 g (in application) |
| Enclosure Rating | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | Compatible with ABB automation and control systems |
| Mounting | DIN Rail or Panel Mounted |
Industry Applications
-
Industrial Automation – Essential for scaling high voltages in industrial automation systems for safe monitoring and control
-
Power Generation – Used in power plants for precise voltage monitoring and signal conditioning of high-voltage equipment
-
Oil & Gas – Supports safe and accurate voltage measurement in hazardous environments, critical for process control and machinery monitoring
-
Energy Distribution – Used in substations and electrical grids to ensure safe and accurate voltage readings for operational efficiency
-
Manufacturing – Facilitates voltage measurement for control systems in manufacturing equipment, improving system reliability and preventing failures
The ABB DATX131 3ASC25H215 Voltage Divider Board is a crucial component for ensuring accurate voltage measurements and signal conditioning in industrial environments. Its robust design, high-voltage compatibility, and integration with ABB automation systems make it ideal for use in applications requiring precise voltage scaling and monitoring.
ABB DATX131 3ASC25H215 Voltage Divider Board is in stock. Please contact us for a quick quote and competitive pricing.
