ABB DSQC104 YB161102-AE Resolver Digital Board
1. Product Overview
The ABB DSQC104 YB161102-AE Resolver Digital Board is a key electronic component used in ABB automation systems. It plays an important role in industrial robot systems, machine vision, and automation control applications. As a high-precision digital signal processing module, the DSQC104 efficiently handles resolver signals and provides accurate feedback data to the system. It ensures system stability and precision through collaboration with other components, making it essential for precision control and data transmission in various automated environments.
The DSQC104 supports high-precision position and speed control, allowing real-time monitoring and adjustment of resolver signals for precise motion control and data exchange interfaces. Its design is not only highly reliable but also capable of withstanding harsh industrial environments, making it an indispensable part of advanced automation and control systems.
2. Key Features
-
High-Precision Signal Processing: The DSQC104 Resolver Digital Board provides high-precision signal conversion and processing, ensuring efficient and stable operation during position and speed control.
-
Real-Time Monitoring and Feedback: The board features real-time data monitoring and can provide instant feedback on input signals, enabling precise control.
-
Adaptability to Harsh Environments: Designed for high temperatures, low temperatures, vibrations, and other industrial environments, the DSQC104 ensures stable performance under various conditions.
-
Flexible Configuration and Integration: The DSQC104 can seamlessly integrate with a variety of devices and systems, adapting to different application requirements.
-
High Reliability and Durability: With strong anti-interference capabilities and durability, it is suitable for long-term continuous operation in industrial environments, ensuring efficient and stable system performance.
3. Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 200× 150 × 75 mm |
| Weight | 1.2 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Product Model | DSQC104 YB161102-AE |
| Manufacturer | ABB |
| Type | Resolver Digital Board |
| Applicable Systems | ABB Automation Control Systems |
| Input Voltage | 24V DC |
| Power Consumption | Max 10W |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
3.3 Performance and Functions
| Item | Specification |
|---|---|
| Input Voltage | 24V DC |
| Power Consumption | Max 10W |
| Response Time | Less than 1 ms |
| Digital Inputs | 8 Digital Inputs |
| Digital Outputs | 8 Digital Outputs |
| Analog Inputs | 2 Analog Inputs |
| Analog Outputs | 2 Analog Outputs |
| Communication Interface | RS-232, RS-485 |
| Data Processing Capacity | High-speed signal processing with real-time feedback data |
| Protection Features | Overcurrent protection, overvoltage protection, overtemperature protection |
3.4 Environmental Specifications
| Item | Specification |
|---|---|
| Operating Temperature Range | -10°C to +50°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% – 95% Non-condensing |
4. Industry Applications
The ABB DSQC104 YB161102-AE Resolver Digital Board is widely used in various industrial automation systems, particularly in applications where high-precision control and data processing are essential. Key applications include:
-
Industrial Robot Systems: As a core component in robot control systems, the DSQC104 Resolver Digital Board ensures high-precision position control and motion feedback during task execution.
-
Precision Measurement and Control: The board is used in precision instruments for position and speed measurement and control, ensuring high-accuracy operation.
-
Automated Production Lines: In automated production lines, the DSQC104 provides accurate signal feedback to motion control systems, ensuring high production efficiency and product quality.
-
Machine Vision Systems: The DSQC104 processes signals from sensors and vision devices, ensuring accurate data collection and analysis in machine vision systems.
ABB DSQC104 YB161102-AE Resolver Digital Board is in stock. Please contact us for a quick quote and competitive pricing.
