ABB DSTA 145 57120001-HP Analog Circuit Board Connection Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DSTA 145 |
| Order Number | 57120001-HP |
| Product Type | Analog Circuit Board Connection Unit |
| Manufacturer | ABB |
| Function | Connection interface for analog input boards, enabling signal termination and wiring |
| Module Support | Compatible with ABB S100 I/O analog input boards |
| Connector Type | Industrial terminal connections for sensor wiring |
| Supported Signals | PT100 temperature sensors (3-wire) |
| Channel Capacity | Up to 31 channels |
| Wiring Type | 3-wire connection |
| Application | Interface for analog signals in industrial control systems |
| Installation | Panel / cabinet mounting |
| Operating Temperature Range | −20 °C to +60 °C |
| Dimensions | 365 × 50 × 180 mm |
| Weight | 0.27 kg |
| Origin | Switzerland |
FAQ
1. What is the main purpose of the DSTA 145 connection unit?
It serves as a termination and interface unit for analog input boards, ensuring stable and organized signal connections between field devices and control modules.
2. What type of sensors can be connected to this unit?
It is primarily designed for PT100 temperature sensors using a 3-wire configuration, commonly used in industrial temperature measurement.
3. How many input channels does the unit support?
The unit supports up to 31 analog channels, allowing multiple sensor inputs within a single module.
4. Is this unit an active or passive component?
It is a passive connection unit, meaning it does not process signals but provides reliable electrical connections and signal routing.
5. Which systems is the DSTA 145 compatible with?
It is designed for ABB Advant and S100 I/O systems, working alongside compatible analog input boards.
6. What are the benefits of using a dedicated connection unit?
It simplifies wiring, improves signal integrity, reduces installation errors, and enhances maintenance efficiency in control cabinets.
7. Does it require a separate power supply?
No, as a connection/termination unit, it does not require an independent power supply to operate.
8. What should be considered during installation?
Proper cable shielding, correct terminal wiring, and secure mounting are essential to ensure accurate signal transmission and minimize interference.
ABB DSTA 145 57120001-HP Analog Circuit Board Connection Unit is in stock. Please contact us for a quick quote and competitive pricing.
