Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | SDCS-FIS-3A |
| Product Type | Field Interface Signal Module |
| Function | Field signal adaptation and isolated communication |
| Input Channels | Multi-type signal inputs (analog/digital) |
| Output Interface | Conditioned and isolated signal output |
| Rated Supply Voltage | 24V DC |
| Signal Isolation | Galvanic isolation between field and control circuits |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -25°C to +75°C |
| Dimensions (L × W × H) | 18.2 cm × 12.0 cm × 4.5 cm |
| Weight | 1.10 kg |
| Installation Method | Standard DIN rail |
| Communication Mode | Field communication interface (proprietary) |
FAQ
-
Q: What is the primary role of the SDCS-FIS-3A module?
A: It is designed to adapt field-level signals and convert them into isolated, controller-ready outputs. -
Q: Does it handle both analog and digital inputs?
A: Yes, the module is built to accommodate a variety of input signal types. -
Q: What power supply is required for operation?
A: A regulated 24V DC power source is necessary for stable performance. -
Q: Is galvanic isolation integrated into the design?
A: Yes, galvanic isolation is used to safeguard circuits and reduce interference. -
Q: What mounting configuration does it support?
A: The device is intended for installation on standard DIN rails. -
Q: How durable is the unit in varying temperatures?
A: It operates reliably between -10°C and +60°C, making it suitable for industrial conditions. -
Q: What are the overall dimensions of the SDCS-FIS-3A?
A: Its size is 18.2 cm × 12.0 cm × 4.5 cm. -
Q: How much does the module weigh?
A: The unit has a weight of approximately 1.10 kg.
