ABB TU846 3BSE022460R1 Module Termination Unit
Product Overview
The ABB TU846 3BSE022460R1 is a compact Module Termination Unit (MTU) designed for use with Field Control Interface (FCI) applications within the ABB S800 I/O system, part of the AC 800M platform. It provides the physical interface between field signals and I/O modules, allowing secure and efficient signal termination in a modular DIN rail-mounted format.
The TU846 offers streamlined signal management for various I/O functions and supports redundant configurations through its integration with appropriate modules. It features quick-connect terminal blocks, system power distribution, and diagnostics support, making it ideal for both new installations and retrofits in process automation environments.
Key Features
-
Direct Mounting for FCI Modules – Allows FCI communication modules to plug directly onto the unit
-
Compact DIN Rail Design – Space-saving form factor with easy installation
-
Integrated Power Distribution – Delivers power to connected modules through internal bus
-
36 Field Signal Terminals – Screw terminals for secure and clear field wiring
-
Support for Redundancy – Compatible with redundant system configurations
-
LED Indicators – Simplifies status monitoring and troubleshooting
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 124 x 186 x 47 mm |
| Weight | 0.5 kg |
Electrical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24 VDC (from system backplane or terminal) |
| Power Distribution | Internal bus to I/O or FCI modules |
| Field Terminals | 36 screw terminals |
| Module Interface | Backplane connector for FCI module |
Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5%–95% RH (non-condensing) |
| Enclosure Rating | IP20 |
System Compatibility
| Item | Specification |
|---|---|
| System Integration | Fully compatible with ABB S800 I/O and AC 800M systems |
| Supported Modules | FCI communication modules and I/O modules |
| Engineering Tools | ABB Control Builder and 800xA suite |
Industry Applications
-
Power Generation – Facilitates reliable I/O wiring in power plant automation systems
-
Oil & Gas – Suitable for critical I/O interfacing in upstream, midstream, and downstream operations
-
Chemical and Petrochemical – Ensures robust signal termination in process control systems
-
Water and Wastewater – Used for efficient field integration in pumping and treatment stations
-
Pharmaceutical and Food – Supports hygienic automation systems with modular design
The ABB TU846 3BSE022460R1 Module Termination Unit is a reliable and space-efficient solution for interfacing field signals with FCI and I/O modules in ABB control systems. With its compact design, robust connectivity, and compatibility with redundant configurations, it plays a critical role in ensuring dependable automation in a wide range of industrial environments.
ABB TU846 3BSE022460R1 Module Termination Unit is in stock. Please contact us for a quick quote and competitive pricing.
