Allen Bradley 1336-SN-SP14A Inverter Snubber
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | 1336 Series |
| Model | 1336-SN-SP14A |
| Product Type | Inverter Snubber PCB |
| Part Number | 1336-SN-SP14A |
| Application | Inverter / AC Drive Protection |
| Compatible Drive Family | 1336STEF |
| Rated Voltage | 460 VAC |
| Applicable Drive Power | X250–800 HP |
| Applicable Frame / Configuration | A21–A23 |
| Circuit Function | Inverter switching transient suppression |
| Protection Function | Reduces voltage spikes and electrical stress on inverter power components |
| Installation Type | PCB-mounted replacement component |
| Typical Quantity per Drive | 3 boards |
| Board Type | Inverter Snubber Board |
| Dimensions | 165 × 40 × 100 mm |
| Weight | 0.64 kg |
FAQ
1. What is the Allen-Bradley 1336-SN-SP14A used for?
The 1336-SN-SP14A is an inverter snubber PCB used in compatible Allen-Bradley 1336 series drives. Its primary function is to suppress switching transients and reduce electrical stress on the inverter power circuit.
2. Which Allen-Bradley drives are compatible with the 1336-SN-SP14A?
The 1336-SN-SP14A is specified for 1336STEF drives operating at 460 VAC and covering X250–800 HP configurations, particularly A21–A23 configurations. The exact drive catalog number should be checked before replacement.
3. What voltage rating does the 1336-SN-SP14A support?
The 1336-SN-SP14A is specified for 460 VAC 1336STEF inverter applications. It should not be substituted into another voltage class without confirming the drive’s spare-parts configuration.
4. How does the 1336-SN-SP14A protect the inverter?
The snubber network absorbs and limits high-frequency voltage transients generated during inverter switching. This helps reduce voltage stress on power switching devices and associated inverter circuitry.
5. How many 1336-SN-SP14A boards are normally used in one drive?
The 1336 spare-parts configuration specifies three inverter snubber boards for the applicable 460 VAC X250–800 HP drive configurations. Replacement should therefore consider the complete snubber arrangement rather than only one board.
6. What are common symptoms of a defective inverter snubber board?
Possible symptoms include abnormal inverter operation, increased switching-related electrical noise, repeated power-device failures, visible PCB damage, or abnormal voltage transients. A snubber fault should be investigated together with the IGBT/power section and associated wiring.
7. What should be checked before replacing the 1336-SN-SP14A?
Verify the complete drive catalog number, 460 VAC rating, X250–800 HP range, A21–A23 configuration, and existing snubber arrangement. The drive should be fully isolated from power and the DC bus confirmed discharged before servicing.
8. What precautions are required when installing the 1336-SN-SP14A?
Because the board is part of a high-voltage drive circuit, qualified personnel should perform the replacement. Follow ESD precautions when handling the PCB, inspect connectors and mounting points for damage, and ensure all connections are correctly seated before energizing the drive.
Allen Bradley 1336-SN-SP14A Inverter Snubber is in stock. Please contact us for a quick quote and competitive pricing.
