Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1746-IN16/C |
| Product Type | Digital Input Module |
| Series | SLC 500 |
| Manufacturer | Allen-Bradley |
| Input Type | DC Digital Input |
| Number of Inputs | 16 Channels |
| Input Voltage Range | 10–30V DC |
| Input Logic | Sink/Source compatible (system dependent) |
| Backplane Power | Supplied via SLC 500 chassis backplane |
| Response Time | Fast industrial response |
| Electrical Isolation | Channel-to-backplane isolation |
| Status Indicators | LED per channel |
| Mounting Type | SLC 500 chassis slot-mounted |
| Communication | Backplane communication with PLC processor |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% RH (Non-condensing) |
| Vibration Resistance | Industrial-grade mechanical design |
| EMC Protection | Industrial electromagnetic compatibility design |
| Protection Class | Open-type equipment for control cabinet use |
| Application Area | Industrial automation and process control systems |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| Weight | 0.27 kg |
FAQ
1. What is the main function of the 1746-IN16/C Digital Input Module?
The 1746-IN16/C is designed to acquire DC digital signals from field devices and transmit them to the SLC 500 PLC processor. It converts discrete ON/OFF electrical signals from devices such as push buttons, sensors, limit switches, and relay contacts into digital data that the PLC can process. This enables real-time monitoring and control of industrial systems.
2. What type of systems commonly use this module?
This module is widely used in Allen-Bradley SLC 500 PLC-based automation systems. Typical applications include manufacturing production lines, packaging systems, conveyor systems, water treatment facilities, and general industrial automation environments requiring reliable multi-channel digital input monitoring.
3. What input signal range does the module support?
The module supports 10–30V DC digital input signals. It is designed to detect voltage presence or absence, representing ON/OFF logic states. This makes it suitable for modern low-voltage industrial control circuits and sensor-based automation systems.
4. How does the module communicate with the PLC?
The module communicates directly with the SLC 500 processor through the chassis backplane. Once installed, it is automatically recognized by the system and continuously exchanges input status data with the CPU in real time, without requiring additional communication setup.
5. Does the module provide electrical isolation?
Yes, it provides channel-to-backplane isolation. This isolation protects the PLC system from electrical noise, voltage spikes, and grounding disturbances originating from field wiring, helping ensure stable and reliable operation in industrial environments.
6. What diagnostic features are included?
Each input channel is equipped with an LED indicator that displays real-time signal status. These indicators allow maintenance personnel to quickly identify active or inactive inputs, significantly improving troubleshooting efficiency and reducing downtime during system diagnostics.
7. What should be considered during installation?
The module must be installed into a compatible SLC 500 chassis slot, ensuring proper engagement with the backplane. It should be mounted in a control cabinet that meets industrial environmental standards, including controlled temperature, humidity, and electromagnetic interference protection.
8. Does the module require regular maintenance?
The module requires minimal maintenance under normal operating conditions. However, periodic inspection of wiring integrity, chassis seating, and LED indicators is recommended. Maintaining a clean control cabinet environment helps ensure long-term reliability and prevents intermittent signal issues.
Allen Bradley 1746-IN16/C SLC 500 Digital Input Module is in stock. Please contact us for a quick quote and competitive pricing.
