Allen Bradley 1746-NO41 SLC 500 4-Channel Analog Current Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Specification | Details |
|---|---|
| Product Model | 1746-NO4I |
| Product Type | SLC 500 4-Channel Analog Current Output Module |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Series | SLC 500 1746 Series |
| Main Function | Provides four-channel analog current outputs for controlling industrial field devices |
| Application | Process control, industrial automation, actuator control, analog signal generation |
| Output Channels | 4 analog output channels |
| Output Type | Current output |
| Output Range | 0…20 mA |
| Resolution | 14-bit digital-to-analog conversion |
| Output Accuracy | ±0.541% of full scale (0…60°C typical) |
| Non-Linearity | ±0.05% of full scale |
| Step Response Time | 2.5 ms (5…95%) |
| Load Resistance Range | 0…500 Ω |
| Maximum Load Reactance | 100 μH |
| Isolation | Backplane isolation for analog signals |
| Channel Filtering | Output filtering supported |
| Update Method | Automatic end-of-scan updates |
| Terminal Connection | Removable terminal block |
| Backplane Current Draw | 55 mA @ 5 VDC |
| External 24VDC Current Draw | 195 mA @ 24 VDC |
| External Power Supply | 24 VDC ±10% |
| Compatible Controllers | Allen-Bradley SLC 500 processors |
| Compatible Chassis | 1746 SLC 500 chassis |
| Programming Software | RSLogix 500 |
| Status Indicators | Module status LED |
| Mounting Method | SLC 500 chassis slot mounting |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 145 × 35 × 140 mm |
| Weight | Approx. 0.3 kg |
| Enclosure Type | Open-style module |
| Typical Applications | Control valves, analog actuators, variable speed drives, process instrumentation, machine control systems |
FAQ
Q1: What is the 1746-NO4I mainly used for?
A: The 1746-NO4I is an SLC 500 analog output module used to generate 0–20 mA current signals for controlling industrial devices such as valves, actuators, and drives.
Q2: How many output channels does the 1746-NO4I provide?
A: The module provides four independent analog current output channels.
Q3: What type of output signal does the 1746-NO4I support?
A: It supports 0–20 mA analog current output signals.
Q4: What is the resolution of the 1746-NO4I?
A: The module provides 14-bit digital-to-analog conversion for accurate analog output control.
Q5: Which PLC systems are compatible with the 1746-NO4I?
A: It is designed for Allen-Bradley SLC 500 PLC systems using 1746 chassis platforms.
Q6: What software is used to configure the 1746-NO4I?
A: Configuration and programming are performed through RSLogix 500 software with compatible SLC 500 processors.
Q7: Can the 1746-NO4I be used in process control applications?
A: Yes. It is commonly used for analog control applications such as flow control, pressure regulation, valve positioning, and speed references.
Q8: What are the main advantages of the 1746-NO4I?
A: It provides reliable four-channel analog current output, high-resolution signal conversion, removable terminal wiring, and compatibility with existing SLC 500 automation systems.
Allen Bradley 1746-NO41 SLC 500 4-Channel Analog Current Output Module is in stock. Please contact us for a quick quote and competitive pricing.
