Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital Output Module |
| Model Number | 1756-OB16DK |
| Series | Allen-Bradley ControlLogix |
| Module Type | 16-Point Diagnostic DC Output Module |
| Output Type | 24V DC Sourcing Outputs |
| Number of Outputs | 16 Outputs (8 points per group) |
| Operating Voltage Range | 19.2–30V DC |
| Current Rating per Point | 2 A @ 30°C, 1 A @ 60°C |
| Current Rating per Module | 8 A @ 30°C, 4 A @ 60°C |
| Output Delay Time | OFF to ON: 60 µs nominal; ON to OFF: 630 µs nominal |
| Isolation Voltage | 250V Continuous |
| Current Draw @ 5.1V | 250 mA |
| Current Draw @ 24V | 140 mA |
| Total Backplane Power | 4.64 W |
| Power Dissipation | Approx. 3.3 W @ 60°C |
| Thermal Dissipation | Approx. 11.25 BTU/hr |
| Conformal Coating | Yes (“K” suffix protection) |
| Diagnostics Features | No-load detection, output state verification, electronic fusing |
| Compatible Chassis | 1756 ControlLogix Chassis |
| Terminal Block Compatibility | 1756-TBCH, 1756-TBS6H |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (L × W × H) | Approx. 144.57 × 22 × 105.42 mm |
| Weight | Approx. 0.24 kg |
| Key Features | High-performance 16-point diagnostic DC output module with conformal coating, electronic protection, field-side diagnostics, and reliable industrial automation control |
FAQ
- What is the 1756-OB16DK used for?
It is a 16-point DC digital output module used in Allen-Bradley ControlLogix systems for industrial automation output control. - What type of outputs does it provide?
It provides 24V DC sourcing outputs with diagnostic capabilities. - What does the “K” suffix mean?
The “K” indicates conformal coating for additional protection against moisture, dust, and corrosive industrial environments. - How many output points are available?
The module includes 16 diagnostic output channels arranged in two groups of 8 points. - What diagnostic functions are included?
Features include no-load detection, output verification, pulse testing, and per-point electronic fusing. - What terminal blocks are compatible?
The module supports 1756-TBCH and 1756-TBS6H terminal blocks. - Is the 1756-OB16DK still active?
Yes, Rockwell Automation currently lists this module with Active lifecycle status.
