Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1784-PCIC Communication Interface Card |
| Product Type | Industrial Equipment |
| Device Type | PCI DH+ / Remote I/O Communication Card |
| Communication Protocols | Data Highway Plus (DH+), Remote I/O (RIO) |
| Bus Interface | PCI Bus |
| Compatible Systems | Industrial PCs and desktop computers with PCI slot |
| Supported Software | RSLinx, RSLogix, FactoryTalk legacy communication software |
| Communication Speed | Up to 230.4 Kbps (DH+) |
| Network Media | Twinaxial cable |
| Connector Type | 3-pin Phoenix-style connector |
| Number of Channels | Single communication channel |
| LED Indicators | Communication and network activity LEDs |
| Power Source | Powered through PCI bus |
| Mounting Type | Internal PCI expansion card |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Dimensions (L × W × H) | Approx. 175 × 107 × 20 mm |
| Weight | Approx. 0.2–0.4 kg |
| Typical Applications | PLC programming, DH+ network access, Remote I/O communication, legacy industrial automation systems |
FAQ
What is the 1784-PCIC used for?
It is a PCI communication interface card used to connect PCs to Allen-Bradley DH+ and Remote I/O networks.
Which communication protocols does it support?
It supports Data Highway Plus (DH+) and Remote I/O (RIO) communication.
What type of PC slot is required?
It requires a standard PCI expansion slot.
Can it be used in modern computers?
It can only be used in systems that still include legacy PCI slots, not PCIe-only systems.
What software is commonly used with the 1784-PCIC?
It is commonly used with RSLinx, RSLogix, and other Rockwell Automation legacy software platforms.
What is the maximum communication speed?
It supports DH+ communication speeds up to 230.4 Kbps.
Is this product considered legacy hardware?
Yes, it is considered a legacy communication interface product but remains in use in older automation systems.
Where is the 1784-PCIC commonly installed?
It is commonly installed in industrial PCs, maintenance workstations, and PLC programming computers requiring DH+ network access.
Allen Bradley 1784-PCIC Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
