Allen Bradley 20DJ096A3NNNA1CNL PowerFlex 700S AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Drive |
| Manufacturer | Allen-Bradley |
| Series | PowerFlex 700S |
| Model | 20DJ096A3NNNA1CNL |
| Drive Rating | 96 A |
| Normal-Duty Power Rating | 75 HP / 55 kW |
| Heavy-Duty Power Rating | 60 HP / 45 kW |
| DC Bus Voltage | 650 VDC |
| Input Type | DC Input |
| Frame Size | Frame 5 |
| Input Configuration | DC Input, 650 VDC |
| Output Current | 96 A continuous |
| 1-Minute Current Rating | 106 A normal duty / 116 A heavy duty |
| 3-Second Current Rating | 144 A normal duty / 154 A heavy duty |
| Enclosure Rating | IP20 / NEMA Type 1 |
| Control | PowerFlex 700S Phase II Control |
| Human Interface Module | Full Numeric LCD |
| Communication | DriveLogix ControlNet |
| Encoder Feedback | Incremental Encoder |
| Cassette | Expanded Cassette |
| Logix Expansion | Included |
| EMC Filter | CE Filter |
| Common-Mode Choke | Included |
| Brake IGBT | Not Included |
| Brake Resistor | Not Included |
| Cooling | Forced-Air Cooling |
| Mounting | Panel Mount |
| Dimensions | 657 × 275.4 × 339.9 mm |
| Weight | 37.19 kg |
| Typical Application | High-performance motor speed and torque control |
| Product Status | Discontinued |
FAQ
1. What is the Allen-Bradley 20DJ096A3NNNA1CNL used for?
The 20DJ096A3NNNA1CNL is a PowerFlex 700S high-performance AC drive designed for demanding industrial motor-control applications. It provides precise speed and torque control and is suitable for systems requiring advanced drive coordination and feedback.
2. What is the current rating of the 20DJ096A3NNNA1CNL?
The drive has a continuous output current rating of 96 A. The available short-term current ratings are higher, with separate ratings specified for normal-duty and heavy-duty operation.
3. What motor power can this PowerFlex 700S drive handle?
The drive is rated for 75 HP (55 kW) under normal-duty operation and 60 HP (45 kW) under heavy-duty operation. The actual motor rating should be selected according to the application load profile and required overload capacity.
4. What DC voltage does the 20DJ096A3NNNA1CNL require?
This model is designed for a 650 VDC input. It belongs to the PowerFlex 700S 650 VDC input drive family and uses a DC bus configuration rather than a conventional three-phase AC input.
5. Does the 20DJ096A3NNNA1CNL support encoder feedback?
Yes. This configuration includes an incremental encoder interface. Encoder feedback can be used for closed-loop speed and torque control where higher motion-control accuracy is required.
6. What control system is used with this PowerFlex 700S drive?
The 20DJ096A3NNNA1CNL uses PowerFlex 700S Phase II control and includes DriveLogix ControlNet functionality. It can therefore be integrated into industrial control architectures requiring coordinated drive and controller communication.
7. Does this model include a braking resistor or brake IGBT?
No. The specified configuration is supplied without a brake IGBT and without a drive-mounted braking resistor. If dynamic braking is required, the braking arrangement should be designed separately according to the application and drive system requirements.
8. What should be checked when commissioning the 20DJ096A3NNNA1CNL?
Before commissioning, verify the DC bus supply, motor ratings, control parameters, encoder wiring, grounding, communication connections, cooling conditions, and protection settings. The motor feedback direction and drive configuration should also be tested at low speed before normal operation.
Allen Bradley 20DJ096A3NNNA1CNL PowerFlex 700S AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
