Allen Bradley 20F11NE011JA0NNNNN PowerFlex 753 AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 20F11NE011JA0NNNNN |
| Product Type | AC Drive |
| Series | PowerFlex 753 |
| Brand | Allen-Bradley |
| Drive Type | Air-Cooled AC Drive |
| Input Voltage | 600 VAC, 3-Phase |
| Input Frequency | 50/60 Hz |
| Normal-Duty Output Current | 11 A |
| Heavy-Duty Output Current | 9 A |
| Normal-Duty Power | 10 HP / 7.5 kW |
| Heavy-Duty Power | 7.5 HP / 5.5 kW |
| Frame Size | Frame 3 |
| Input Type | AC Input with Precharge and DC Terminals |
| Enclosure Type | IP20/IP00, NEMA/UL Open Type |
| Cooling Method | Forced Air |
| Embedded I/O | Included |
| EMC Filtering | Filtered |
| Common Mode Capacitor Jumper | Installed |
| Dynamic Braking | Internal DB Transistor |
| HMI | Blank Cover, No HIM |
| Control Method | V/Hz, Sensorless Vector and Flux Vector Control |
| Operating Temperature | 0–50°C |
| Relative Humidity | 5–95%, Non-Condensing |
| Application | Industrial Motor Speed and Torque Control |
| Dimensions | 454 × 190 × 212 mm |
| Weight | 11.8 kg |
FAQ
1. What is the rated output current of the Allen-Bradley 20F11NE011JA0NNNNN?
The 20F11NE011JA0NNNNN provides an 11 A normal-duty output rating and a 9 A heavy-duty output rating. The correct rating should be selected according to the actual load profile. For applications with frequent acceleration, high starting torque, or significant overload requirements, the heavy-duty rating should be considered during drive selection.
2. What input voltage does the 20F11NE011JA0NNNNN support?
This PowerFlex 753 drive is designed for a 600 VAC, three-phase power system. It uses an AC input configuration with precharge and DC terminals. Before energizing the drive, verify the incoming voltage, phase configuration, protective grounding, and input wiring to ensure they comply with the installation requirements.
3. What motor power ratings are supported by this PowerFlex 753 drive?
The 20F11NE011JA0NNNNN is rated for 10 HP (7.5 kW) under normal-duty conditions and 7.5 HP (5.5 kW) under heavy-duty conditions. Motor selection should also consider full-load current, starting torque, acceleration requirements, load inertia, and the required overload capability rather than relying only on the motor horsepower.
4. Does the 20F11NE011JA0NNNNN have an internal dynamic braking transistor?
Yes. The drive includes an internal dynamic braking transistor. During rapid deceleration, regenerative energy from the motor can increase the DC bus voltage. An appropriately rated external braking resistor can be connected to dissipate this energy. Braking resistor selection should consider motor inertia, deceleration time, braking frequency, and the required stopping performance.
5. What cooling method is used by the 20F11NE011JA0NNNNN?
The 20F11NE011JA0NNNNN uses forced-air cooling. Internal fans and heat sinks remove heat generated by the drive’s power components. Proper cabinet ventilation and sufficient airflow around the drive are important for reliable operation. Dust accumulation, blocked air passages, and excessive ambient temperature can reduce cooling performance and cause thermal protection.
6. What motor control modes are available on the PowerFlex 753?
The PowerFlex 753 platform supports control strategies including V/Hz and vector-based control. The appropriate mode depends on motor characteristics, load behavior, required speed regulation, and torque response. For vector-control applications, accurate motor nameplate data and appropriate tuning are important for stable speed and torque performance.
7. What parameters should be configured during initial commissioning?
Initial commissioning should include the motor rated voltage, rated current, rated frequency, rated power, and rated speed. The acceleration and deceleration times, minimum and maximum frequency, stopping method, motor rotation direction, and current limits should also be configured. The input supply and grounding should be checked before the drive is energized.
8. How should overcurrent or DC bus overvoltage faults be diagnosed?
For an overcurrent fault, inspect the motor and output wiring for short circuits or ground faults and check whether the mechanical load is excessive or changing abruptly. If a DC bus overvoltage fault occurs during deceleration, check the deceleration time, load inertia, and dynamic braking configuration. The fault code and fault history should be reviewed together with the operating conditions to determine the underlying cause.
