Allen Bradley 20F11RD014AA0NNNNN PowerFlex 753 AC Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | 20F11RD014AA0NNNNN |
| Product Series | PowerFlex 753 |
| Product Type | PowerFlex 753 AC Drive |
| Drive Type | Air-Cooled AC Variable Frequency Drive |
| Voltage Class | 480 V AC |
| Input Voltage Range | 380–480 V AC |
| Input Phase | Three-phase |
| Input Type | AC input with precharge |
| Continuous Output Current | 14 A |
| 1-Minute Overload Current | 15.4 A |
| 3-Second Overload Current | 21 A |
| Normal-Duty Rating | 10 HP |
| Heavy-Duty Rating | 7.5 HP |
| Frame Size | Frame 1 |
| Enclosure Rating | IP20 |
| Enclosure Type | NEMA/UL Open Type |
| Cooling Method | Forced-air cooling |
| Dynamic Braking | Built-in dynamic braking transistor |
| EMC Filtering | Filtered |
| Common-Mode Capacitor | Jumper removed |
| Operator Interface | Blank cover, no HIM |
| Embedded I/O | Supported |
| Motor Control | Variable-frequency motor speed and torque control |
| Communication Expansion | Supported through PowerFlex 753 option modules |
| Typical Applications | Conveyors, pumps, fans, machine tools and industrial motor control |
| Mounting | Control cabinet or panel mounting |
| Dimensions | 400.5 × 110 × 211 mm |
| Weight | 6 kg |
FAQ
1. What is the Allen-Bradley 20F11RD014AA0NNNNN used for?
The Allen-Bradley 20F11RD014AA0NNNNN is a PowerFlex 753 AC drive used for variable-speed control of three-phase AC motors. It is suitable for industrial machinery, conveyors, pumps, fans and other applications where controlled motor acceleration, deceleration and operating speed are required.
2. What are the input voltage and phase requirements for the 20F11RD014AA0NNNNN?
This model belongs to the 480 V AC class and is designed for a three-phase supply in the 380–480 V AC range. Before energizing the drive, verify the actual line voltage and phase configuration. Proper disconnecting equipment, branch-circuit protection and protective grounding should also be provided.
3. What is the current and horsepower rating of the 20F11RD014AA0NNNNN?
The drive has a continuous output current rating of 14 A. Its normal-duty rating is 10 HP, while the heavy-duty rating is 7.5 HP. The drive should be matched to the motor using both motor horsepower and nameplate current, with the appropriate duty rating selected according to the actual load profile.
4. What are the overload capabilities of this PowerFlex 753 drive?
The 20F11RD014AA0NNNNN provides a 1-minute overload current rating of 15.4 A and a 3-second overload current rating of 21 A. These values are important for applications involving temporary increases in torque demand, acceleration or short-duration overload conditions. The required overload cycle should be checked during drive selection.
5. Does the 20F11RD014AA0NNNNN include dynamic braking?
Yes. The drive includes a dynamic braking transistor that can be used with an appropriate external braking resistor. During rapid deceleration, regenerative energy from the motor can be dissipated through the resistor. The braking resistor must be selected according to the motor inertia, braking frequency, required stopping time and applicable drive specifications.
6. What does the EMC filter configuration mean on this model?
The 20F11RD014AA0NNNNN is supplied with filtering, while the common-mode capacitor jumper is configured as removed. This configuration affects the drive’s electrical noise and grounding characteristics. Installation should follow the applicable PowerFlex 753 wiring and EMC requirements, particularly when the drive is installed in a system with sensitive control or communication equipment.
7. What can cause an overcurrent fault on the 20F11RD014AA0NNNNN?
Possible causes include excessive mechanical load, incorrect motor data, an acceleration time that is too short, motor cable faults, phase-to-phase short circuits or ground faults. Check the motor wiring and insulation first, then verify the motor nameplate parameters and acceleration settings. Mechanical binding or a sudden increase in load should also be investigated.
8. What should be checked during commissioning of the 20F11RD014AA0NNNNN?
Before startup, verify the three-phase input supply, motor wiring, grounding, protective devices and control connections. Enter the correct motor nameplate information and configure the required control mode, acceleration and deceleration times, frequency limits and other application parameters. During the initial test, run the motor at low speed and monitor output current, rotation direction, fault status and mechanical response before increasing the speed to the normal operating level.
Allen Bradley 20F11RD014AA0NNNNN PowerFlex 753 AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
