Allen-Bradley 20F1ANF082JN0NNNNN PowerFlex 753 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Series | PowerFlex 753 |
| Product Type | AC Drive |
| Catalog Number | 20F1ANF082JN0NNNNN |
| Input Voltage | 690 VAC |
| Input Phase | 3 Phase |
| Output Current | 82 A |
| Normal Duty Rating | 75 kW |
| Heavy Duty Rating | 55 kW |
| Frame Size | Frame 6 |
| Cooling | Forced Air |
| Enclosure | IP20/IP00, NEMA/UL Open Type |
| Embedded I/O | Yes |
| Input Configuration | AC Input with Precharge |
| DC Terminals | None |
| EMC Filtering | Filtered |
| CM Jumper | Installed |
| Dynamic Braking | None |
| HIM | Blank / No HIM |
| Approx. Dimensions | 665.5 × 308 × 346.4 mm |
| Approx. Weight | 38.6 kg |
The 20F1ANF082JN0NNNNN is a 690 VAC, three-phase PowerFlex 753 drive with an 82 A output rating. Rockwell documentation places this model in Frame 6 with 75 kW normal-duty and 55 kW heavy-duty ratings.
The JN configuration uses the installed CM jumper and does not include the internal dynamic-braking transistor found on the corresponding JA version. It also uses filtered input circuitry, forced-air cooling, embedded I/O, and an open enclosure configuration.
FAQ
Q1: What is the Allen-Bradley 20F1ANF082JN0NNNNN?
A1: It is a PowerFlex 753 AC drive intended for variable-speed control of three-phase industrial motors.
Q2: What voltage does the 20F1ANF082JN0NNNNN use?
A2: The drive is designed for a 690 VAC, three-phase input supply.
Q3: What are the current and power ratings?
A3: The output current rating is 82 A. Its normal-duty rating is 75 kW, while the heavy-duty rating is 55 kW.
Q4: Does this model have an internal dynamic-braking transistor?
A4: No. The JN configuration is the version without the internal dynamic-braking transistor. The JA configuration is the corresponding version with internal dynamic braking.
Q5: What does the JN suffix indicate?
A5: Within this PowerFlex 753 catalog family, the JN configuration identifies the installed CM-jumper arrangement without the internal dynamic-braking option. Rockwell documentation distinguishes the jumper configuration through the catalog-code suffix.
Q6: Does the drive include embedded I/O?
A6: Yes. The 20F1ANF082JN0NNNNN includes embedded I/O for standard drive control and interface requirements.
Q7: What are the approximate dimensions and weight?
A7: The Frame 6 unit is approximately 665.5 mm high, 308 mm wide, and 346.4 mm deep. Its approximate weight is 38.6 kg.
Q8: Is a HIM keypad included with this catalog configuration?
A8: No. The catalog configuration specifies a blank/no-HIM arrangement, so a separate Human Interface Module would be required if local keypad operation is needed.
