Allen-Bradley 20G11BD1K4AN2NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Type | PowerFlex 755 AC Drive |
| Catalog Number | 20G11BD1K4AN2NNNNN |
| Series | PowerFlex 755 |
| Input Voltage | 480 VAC |
| Input Phase | 3 Phase |
| Rated Current | 1420 A |
| Low-Duty Rating | 1350 HP |
| Normal-Duty Rating | 1250 HP |
| Heavy-Duty Rating | 1000 HP |
| Frame | Frame 9 |
| Cooling Method | Air Cooled |
| Communication | Embedded EtherNet/IP |
| Input Configuration | AC Input with Precharge |
| Enclosure | Type 1, IP20 |
| Cabinet Style | 600 mm Deep MCC Style |
| Filtering | EMC Filter |
| CM Jumper | Removed |
| Dynamic Braking | None |
| HIM | Enhanced LCD, Full Numeric, Handheld/Local HIM |
| Dimensions | 600 mm deep MCC-style Frame 9; overall height and width depend on the packaged cabinet configuration |
| Weight | Configuration-dependent |
| Lifecycle Status | Discontinued |
| Discontinued Date | June 30, 2024 |
| Direct Replacement | 20G11BD1K4JN2NNNNN |
The 20G11BD1K4AN2NNNNN is a high-power, air-cooled PowerFlex 755 packaged drive rated at 1420 A for 480 VAC three-phase applications. Rockwell Automation identifies the exact catalog number as a PowerFlex Air Cooled 755 AC Drive and lists AC input with precharge as its input configuration. The AN2 version is part of the packaged-drive catalog family and is associated with the enhanced local HIM configuration.
FAQ
Q1: What is the Allen-Bradley 20G11BD1K4AN2NNNNN?
A: It is a PowerFlex 755 air-cooled AC drive designed for high-power industrial motor control. The unit is configured for 480 VAC three-phase service and has a 1420 A current rating.
Q2: What are the horsepower ratings of this drive?
A: The 20G11BD1K4AN2NNNNN is rated for 1350 HP Low Duty, 1250 HP Normal Duty, and 1000 HP Heavy Duty applications.
Q3: What input voltage does the 20G11BD1K4AN2NNNNN use?
A: The drive uses a 480 VAC, three-phase input. Rockwell Automation specifies the input configuration as AC input with precharge.
Q4: Does this PowerFlex 755 have EtherNet/IP communication?
A: Yes. Embedded EtherNet/IP is part of the PowerFlex 755 platform, allowing the drive to be integrated with compatible industrial control and automation networks.
Q5: What type of operator interface is included?
A: The AN2 configuration uses an Enhanced LCD, full-numeric handheld/local HIM. This interface provides local access to drive parameters, status information, diagnostics, and setup functions.
Q6: What enclosure and cabinet configuration does this model use?
A: The drive is configured as a Type 1, IP20 packaged unit using a 600 mm deep MCC-style arrangement. The exact overall cabinet dimensions depend on the packaged installation.
Q7: Does the 20G11BD1K4AN2NNNNN include dynamic braking?
A: No. This catalog configuration does not include dynamic braking. The configured unit is also associated with EMC filtering and the CM jumper removed.
Q8: Is the 20G11BD1K4AN2NNNNN discontinued?
A: Yes. Rockwell Automation lists the exact model as discontinued effective June 30, 2024. The listed direct replacement is 20G11BD1K4JN2NNNNN.
Allen-Bradley 20G11BD1K4AN2NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
