Allen-Bradley 20G11LC1K0JN4NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Series | PowerFlex 755 |
| Product Type | Air-Cooled AC Packaged Drive |
| Catalog Number | 20G11LC1K0JN4NNNNN |
| Input Voltage | 400 VAC |
| Input Phase | 3 Phase |
| Rated Current | 1040 A |
| Light-Duty Power | 630 kW |
| Normal-Duty Power | 560 kW |
| Heavy-Duty Power | 500 kW |
| Frame Size | Frame 9 |
| Cooling Method | Forced Air |
| Input Type | AC Input with DC Terminals |
| Communication | Embedded EtherNet/IP |
| Enclosure | Type 1, IP20, 800 mm Deep MCC Style |
| Filtering | Filtered |
| CM Jumper | Installed |
| Dynamic Braking | None |
| HIM | Enhanced LCD Full Numeric HIM, IP66 NEMA Type 4X/12 |
| Dimensions | 800 mm deep MCC-style configuration; overall height and width depend on the packaged arrangement |
| Weight | 100kg |
The 20G11LC1K0JN4NNNNN is an Allen-Bradley PowerFlex 755 air-cooled AC packaged drive rated for 400 VAC, three-phase input and 1040 A. Rockwell Automation specifies 630 kW light-duty, 560 kW normal-duty, and 500 kW heavy-duty ratings for this Frame 9 configuration. It uses an 800 mm deep Type 1/IP20 MCC-style enclosure with embedded EtherNet/IP and filtered input.
The JN4 configuration has the CM jumper installed and includes the Enhanced LCD Full Numeric HIM, rated IP66, NEMA Type 4X/12. The catalog description also specifies AC input with DC terminals and no internal dynamic-braking option.
FAQ
Q1: What is the Allen-Bradley 20G11LC1K0JN4NNNNN?
A: It is a PowerFlex 755 air-cooled AC packaged drive designed for high-power three-phase motor control applications.
Q2: What input voltage does this drive use?
A: The 20G11LC1K0JN4NNNNN is designed for a 400 VAC, three-phase input supply.
Q3: What are the current and power ratings?
A: The drive is rated at 1040 A, with 630 kW light-duty, 560 kW normal-duty, and 500 kW heavy-duty ratings.
Q4: What frame size does this PowerFlex 755 use?
A: It uses Frame 9 construction and is packaged in an 800 mm deep MCC-style enclosure.
Q5: Does the drive support EtherNet/IP?
A: Yes. Embedded EtherNet/IP is included for connection to compatible industrial automation and control systems.
Q6: What input configuration does the JN4 model have?
A: The catalog configuration uses AC input with DC terminals. It also has a filtered input and an installed CM jumper.
Q7: What type of HIM is included with the 20G11LC1K0JN4NNNNN?
A: The JN4 version includes an Enhanced LCD Full Numeric HIM with an IP66 NEMA Type 4X/12 rating, making it suitable for local drive monitoring and operation in the specified enclosure environment.
Q8: What are the dimensions and weight of the 20G11LC1K0JN4NNNNN?
A: Rockwell specifies an 800 mm deep MCC-style configuration. The complete package’s height and width depend on the cabinet arrangement, and a reliable total assembly weight is not provided in the available product data. The applicable Rockwell mechanical drawing should be used for installation and handling requirements.
Allen-Bradley 20G11LC1K0JN4NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
