Allen-Bradley 20G11LF1K4AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Product Type | PowerFlex 755 AC Drive |
| Catalog Number | 20G11LF1K4AN0NNNNN |
| Input Voltage | 690 VAC |
| Input Phase | 3 Phase |
| Rated Current | 1400 A |
| Low-Duty Power Rating | 1500 kW |
| Normal-Duty Power Rating | 1400 kW |
| Heavy-Duty Power Rating | 1120 kW |
| Frame Size | Frame 10 |
| Cooling Method | Air Cooled |
| Communication | Embedded EtherNet/IP |
| Input Configuration | AC Input with DC Terminals |
| Enclosure | Type 1, IP20 |
| Cabinet Style | 800 mm Deep MCC Style |
| EMC Filtering | Filtered |
| CM Jumper | Removed |
| Dynamic Braking | None |
| HIM | Blank / No HIM |
| Dimensions | 800 mm deep MCC-style configuration; overall height and width depend on the packaged arrangement |
| Weight | 10kg |
The 20G11LF1K4AN0NNNNN is an Allen-Bradley PowerFlex 755 air-cooled AC drive for high-power three-phase motor applications. Rockwell Automation identifies the exact catalog number as a PowerFlex Air Cooled 755 AC Drive and specifies an EMC filter, no dynamic braking, and an AC input with precharge.
Product listings for this configuration specify 690 VAC, 1400 A, 1500 kW low-duty, 1400 kW normal-duty, and 1120 kW heavy-duty ratings, with embedded EtherNet/IP, Type 1/IP20 protection, an 800 mm deep MCC-style enclosure, a removed CM jumper, and a blank/no-HIM arrangement.
FAQ
Q1: What is the Allen-Bradley 20G11LF1K4AN0NNNNN?
A: It is a PowerFlex 755 AC drive designed for high-power industrial motor-control applications. This model uses an air-cooled Frame 10 configuration.
Q2: What input voltage does the 20G11LF1K4AN0NNNNN use?
A: The drive is designed for a 690 VAC, three-phase input supply.
Q3: What is the rated current of this drive?
A: The rated current is 1400 A. Its published ratings are 1500 kW for low-duty operation, 1400 kW for normal-duty operation, and 1120 kW for heavy-duty operation.
Q4: Does the 20G11LF1K4AN0NNNNN include embedded EtherNet/IP?
A: Yes. Embedded EtherNet/IP is included for communication with compatible industrial automation and control systems.
Q5: What type of cooling does this PowerFlex 755 use?
A: The drive uses air cooling. The high-power Frame 10 configuration uses forced ventilation to remove operating heat and requires suitable cabinet airflow during installation.
Q6: What enclosure configuration is specified?
A: The catalog configuration uses a Type 1, IP20 enclosure in an 800 mm deep MCC-style arrangement.
Q7: What does the AN0 configuration indicate?
A: The AN0 configuration has the CM jumper removed and is supplied with a blank/no-HIM arrangement. The configuration also has no internal dynamic-braking option.
Q8: What are the dimensions and weight of the 20G11LF1K4AN0NNNNN?
A: The packaged configuration uses an 800 mm deep MCC-style arrangement. The exact overall height, width, and final weight depend on the packaged Frame 10 installation, so the applicable mechanical documentation should be used for precise installation and shipping data. Rockwell’s product page provides access to the relevant technical documentation and drawings.
Allen-Bradley 20G11LF1K4AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
