Allen-Bradley 20G11RC8P7JA0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Type | PowerFlex 755 AC Drive |
| Catalog Number | 20G11RC8P7JA0NNNNN |
| Input Voltage | 480 VAC |
| Input Phase | 3 Phase |
| Rated Current | 8.7 A |
| Normal-Duty Rating | 5 HP |
| Heavy-Duty Rating | 5 HP |
| Frame Size | Frame 2 |
| Cooling | Air Cooled / Forced Air |
| Input Type | AC Input with DC Terminals |
| Communication | Embedded EtherNet/IP |
| Enclosure | IP20/IP00, NEMA/UL Open Type |
| Filtering | Filtered |
| CM Jumper | Installed |
| Dynamic Braking | Internal DB Transistor |
| HIM | Blank / No HIM |
| Dimensions | Approx. 424.2 × 134.5 × 212 mm |
| Weight | Approx. 6kg, depending on published configuration data |
The 20G11RC8P7JA0NNNNN is an Allen-Bradley PowerFlex 755 AC drive for three-phase motor-control applications. This Frame 2 drive is designed for a 480 VAC supply and has an output-current rating of approximately 8.7 A. The catalog configuration includes embedded EtherNet/IP, filtered input, an installed CM jumper, and an internal dynamic-braking transistor.
FAQ
Q1: What is the Allen-Bradley 20G11RC8P7JA0NNNNN?
A: It is a PowerFlex 755 AC drive designed for variable-speed control of three-phase industrial motors. The model belongs to the 480 VAC Frame 2 range.
Q2: What input voltage does the 20G11RC8P7JA0NNNNN use?
A: The drive is designed for a 480 VAC, three-phase input supply.
Q3: What is the rated current of this PowerFlex 755 drive?
A: The drive has an output-current rating of approximately 8.7 A.
Q4: What are the normal-duty and heavy-duty power ratings?
A: The catalog configuration is rated at approximately 5 HP for normal-duty operation and 5 HP for heavy-duty operation.
Q5: Does the 20G11RC8P7JA0NNNNN support EtherNet/IP?
A: Yes. Embedded EtherNet/IP is included, allowing the drive to communicate with compatible PLCs, controllers, and other industrial automation equipment.
Q6: Does this model include dynamic braking?
A: Yes. The JA0 configuration includes an internal dynamic-braking transistor, which can be used for applications requiring controlled deceleration.
Q7: Does the 20G11RC8P7JA0NNNNN include a HIM keypad?
A: No. The configuration is specified as Blank / No HIM. A compatible Human Interface Module can be added separately when local operator access is required.
Q8: What are the dimensions and weight of the 20G11RC8P7JA0NNNNN?
A: The Frame 2 configuration is approximately 424.2 mm high × 134.5 mm wide × 212 mm deep. Published distributor data can vary on weight, so the final mechanical documentation should be used when exact installation weight is required.
Allen-Bradley 20G11RC8P7JA0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
