Allen-Bradley 20G1AJC540JN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ

  • Manufacturer: Allen-Bradley
  • Product Number: 20G1AJC540JN0NNNNN
  • Condition: New & In Stock
  • Product Type: AC input with precharge, no DC terminals
  • Origin: USA
  • Payment Methods: T/T, Western Union
  • Dimensions: 2477 × 600 × 800 mm
  • Weight : 644 kg;
  • Shipping Port: Xiamen, China
  • Lead Time: 1-3 Working Days
  • Warranty: One Year
  • Certificate: COO
  • Courier partners: DHL, UPS, TNT, FedEx and EMS.

Product Detail

Contact Us

FAQS

Packing & Delivery

Company Information
e-mail [email protected]
Mobile +8613666084105
Whatsapp +8613666084105
WeChat 13666084105
Add to Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Allen-Bradley 20G1AJC540JN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Product Family PowerFlex 755 AC Drive
Catalog Number 20G1AJC540JN0NNNNN
Voltage Rating 400 VAC, 3-phase
Output Current 540 A
Light Duty Rating 585 A / 315 kW
Normal Duty Rating 540 A / 315 kW
Heavy Duty Rating 456 A / 250 kW
Frame Size Frame 8
Cooling Forced air
Input Type AC input with precharge, no DC terminals
Enclosure Type 12 / IP54, 800 mm deep MCC style
EMC Filtering Filtered
CM Jumper Installed
Dynamic Braking None
HIM Blank / No HIM
Communication Embedded EtherNet/IP
Fan Type Backward-curved centrifugal fan
Airflow Approx. 1,805 m³/h
Dimensions Approx. 2477 × 600 × 800 mm (H × W × D), MCC cabinet configuration
Weight Approx. 644 kg; configuration-dependent
Lifecycle Status Active
Warranty 1 year

Rockwell Automation lists the exact 20G1AJC540JN0NNNNN as an Active PowerFlex 755 AC Drive. Its published configuration is 400 VAC, 3-phase, 540 A, Frame 8, forced air cooled, Type 12/IP54, with an 800 mm deep MCC-style enclosure, EMC filtering, CM jumper installed, no dynamic braking, and no HIM.

The published Frame 8 Type 12/MCC dimensions are approximately 2477 mm high × 600 mm wide × 800 mm deep, with an approximate weight of 644 kg. Actual dimensions and weight should be checked against the applicable mechanical drawing for the final installation configuration.

FAQ

Q1: What is the 20G1AJC540JN0NNNNN?
The 20G1AJC540JN0NNNNN is an Allen-Bradley PowerFlex 755 air-cooled AC drive designed for high-power three-phase motor control. It includes embedded EtherNet/IP and is configured for a 400 VAC system.

Q2: What is the output current of this drive?
The drive has a 540 A Normal Duty output rating. Rockwell also specifies 585 A Light Duty and 456 A Heavy Duty ratings for this configuration.

Q3: What motor power can the 20G1AJC540JN0NNNNN handle?
The published ratings are 315 kW for Light Duty, 315 kW for Normal Duty, and 250 kW for Heavy Duty operation.

Q4: What type of enclosure does it use?
It uses a Type 12 / IP54, 800 mm deep MCC-style enclosure. This makes it suitable for demanding industrial installations where increased enclosure protection is required.

Q5: Does this model have an operator HIM?
No. The standard configuration is Blank (No HIM). A compatible HIM can be added separately when local operator access is required.

Q6: Does the drive support EtherNet/IP?
Yes. Embedded EtherNet/IP communication is included in the 20G1AJC540JN0NNNNN configuration, allowing integration with Rockwell Automation control systems and industrial networks.

Q7: Does it include dynamic braking?
No. Rockwell specifies None for the dynamic-braking configuration of this catalog number.

Q8: Is the 20G1AJC540JN0NNNNN still available?
Yes. Rockwell currently lists this exact catalog number as Active. It is also the direct replacement for the discontinued 20G1AJC540AN0NNNNN, which was discontinued on June 30, 2024.

Allen-Bradley 20G1AJC540JN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
