Allen-Bradley 20G1AJC650AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Manufacturer |
Allen-Bradley / Rockwell Automation |
|
Product Family |
PowerFlex 755 |
|
Catalog Number |
|
|
Product Type |
|
|
Voltage Rating |
400 VAC, 3-phase |
|
Output Current |
650 A |
|
Light Duty Rating |
Approx. 700 A / 400 kW |
|
Normal Duty Rating |
650 A / 355 kW |
|
Heavy Duty Rating |
Approx. 540 A / 300 kW |
|
Frame Size |
Frame 8 |
|
Cooling |
Forced air |
|
Input Type |
AC input with precharge, no DC terminals |
|
Enclosure |
Type 12 / IP54, 800 mm deep MCC style |
|
EMC Filtering |
EMC filter |
|
CM Jumper |
Removed |
|
Dynamic Braking |
None |
|
HIM |
Blank / No HIM |
|
Communication |
Embedded EtherNet/IP |
|
Dimensions |
2453 × 600 × 600 mm |
|
Weight |
600kg |
|
Lifecycle Status |
Discontinued |
|
Discontinued Date |
June 30, 2024 |
|
Direct Replacement |
20G1AJC650JN0NNNNN |
|
Standard Warranty |
1 year |
Rockwell Automation identifies the exact 20G1AJC650AN0NNNNN as a discontinued PowerFlex 755 AC Packaged Drive. The official product page confirms its EMC filtering, absence of dynamic braking, one-year standard warranty, and direct replacement model 20G1AJC650JN0NNNNN. The discontinuation date was June 30, 2024.
FAQ
Q1: What is the 20G1AJC650AN0NNNNN? The 20G1AJC650AN0NNNNN is an Allen-Bradley PowerFlex 755 air-cooled AC drive designed for high-power three-phase industrial motor applications.
Q2: What is the voltage rating of this drive? It belongs to the 400 VAC-class PowerFlex 755 family. Confirm the permitted input-voltage range on the drive nameplate and technical documentation before installation.
Q3: What is the output current rating? The model number corresponds to the 650 A class. The continuous current available in service depends on the selected duty rating and operating conditions.
Q4: What type of enclosure does it use? This catalog configuration is associated with a Type 12 / IP54, 800 mm deep MCC-style package. Check the original mechanical drawing to confirm clearance and installation requirements.
Q5: Does the 20G1AJC650AN0NNNNN include a HIM? No. The AN0 configuration is supplied without a Human Interface Module (HIM). A compatible operator interface can be selected separately if local operation or parameter access is needed.
Q6: Does this drive support EtherNet/IP? Yes. The PowerFlex 755 platform provides embedded EtherNet/IP communication for integration with compatible industrial automation systems.
Q7: Does it include dynamic braking? No. Rockwell’s listing specifies no dynamic braking for this catalog number. Applications that require rapid deceleration should be reviewed for suitable braking options.
Q8: Is the 20G1AJC650AN0NNNNN still available? Rockwell Automation lists the model as Discontinued, effective June 30, 2024. The specified direct replacement is 20G1AJC650JN0NNNNN. Availability of remaining inventory or repair services may vary by supplier.
Allen-Bradley 20G1AJC650AN0NNNNN PowerFlex 755 AC Drive – Technical Specifications and FAQ is in stock. Please contact us for a quick quote and competitive pricing.
