Allen Bradley 20P41AB038RA0NNN PowerFlex DC Drives
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Model | 20P41AB038RA0NNN |
| Product Series | PowerFlex DC Drives |
| Product Type | Regenerative Digital DC Drive |
| Rated Input Voltage | 240 V AC (208 V AC supply designation) |
| Input Phase | Three-phase |
| Input Type | 6-pulse rectifier |
| Rated DC Output Current | 38 A |
| Rated Motor Power | 10 HP / 7.5 kW |
| Motor Operation | Four-quadrant regenerative operation |
| Frame Size | Frame A |
| Field Supply | Single-phase regulated |
| Enclosure Rating | IP20 |
| Enclosure Type | NEMA/UL Type Open |
| Circuit Board Protection | Conformal coating |
| Human Interface Module (HIM) | Not included; blank plate installed |
| Communication Module | Not included |
| Standard I/O | 8 digital inputs, 4 digital outputs, 3 analog inputs, 2 analog outputs |
| Overload Capability | 150% for 60 seconds; 200% for 3 seconds, under specified conditions |
| Control Function | DC motor speed and torque control |
| Dimensions | 359 × 267 × 287 mm |
| Weight | 11.5 kg |
