Allen Bradley 20P41AB055RA0NNN PowerFlex DC Drives
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Model | 20P41AB055RA0NNN |
| Product Series | PowerFlex DC Drives |
| Product Type | Regenerative Digital DC Drive |
| Rated Input Voltage | 230 V AC nominal; 200–240 V AC input class |
| Input Phase | Three-phase |
| Input Type | 6-pulse rectifier |
| Rated DC Output Current | 55 A |
| Rated Motor Power | 15 HP / 11 kW |
| Motor Operation | Four-quadrant regenerative operation |
| Frame Size | Frame A |
| Field Supply | Single-phase regulated |
| Enclosure Rating | IP20 |
| Enclosure Type | NEMA/UL Type Open |
| Circuit Board Protection | Conformal coating |
| Human Interface Module (HIM) | Not included; blank plate installed |
| Communication Module | Not included |
| Standard I/O | 8 digital inputs, 4 digital outputs, 3 analog inputs, 2 analog outputs |
| Overload Capability | 150% for 60 seconds; 200% for 3 seconds, under specified conditions |
| Control Function | DC motor speed and torque control |
| Dimensions | 359 × 267 × 287 mm |
| Weight | 11.5 kg |
FAQ
Q1: What is the main function of the Allen-Bradley 20P41AB055RA0NNN?
A: The Allen-Bradley 20P41AB055RA0NNN is a PowerFlex DC drive designed to regulate the speed and torque of compatible DC motors. Its regenerative design supports controlled acceleration, deceleration, and energy feedback during braking. It is suitable for industrial machinery that requires precise speed control, frequent reversing, or repeated braking cycles.
Q2: What are the input voltage and rated output current of this drive?
A: This model is designed for a three-phase AC supply in the 200–240 V class, with a nominal 230 V AC rating. Its rated DC output current is 55 A. Before commissioning, verify the actual supply voltage, motor armature ratings, field requirements, and protective device selection against the drive nameplate and installation manual.
Q3: What motor power is supported by the 20P41AB055RA0NNN?
A: The drive is rated for a 15 HP motor, equivalent to approximately 11 kW, under specified operating conditions. Check the motor’s armature voltage, rated current, field current, and duty cycle before installation. The drive must be correctly matched to the motor and the application’s load characteristics.
Q4: How does four-quadrant regenerative operation work?
A: Four-quadrant operation allows the drive to control forward and reverse rotation, along with motoring and regenerative braking. During braking, energy generated by the motor can be returned to the AC supply. This is useful for equipment with frequent deceleration, reversing, or overhauling loads, provided the power system is configured for regenerative operation.
Q5: Does this model include a Human Interface Module or communication module?
A: No. This configuration is supplied without a Human Interface Module (HIM) and without a communication module. Parameter setup and diagnostics may require compatible programming tools or optional interface equipment. PLC or DCS integration depends on the available I/O, installed communication options, and the overall control system design.
Q6: What should be checked if the motor fails to start?
A: Check the three-phase input supply, upstream circuit protection, drive enable and start commands, emergency-stop circuit, and active fault codes. Inspect the armature and field wiring, feedback signals where applicable, and drive parameter settings. Identify and correct the cause of the fault before resetting the drive.
Q7: How can overcurrent faults or unstable motor speed be diagnosed?
A: Start by checking the motor nameplate data and drive configuration. Inspect the armature circuit, field supply, speed feedback device, mechanical load, and reference signal. Compare the commanded speed with the actual feedback and review the fault history. If the problem occurs during acceleration or deceleration, check the ramp settings and load conditions.
Q8: What precautions are required when installing or replacing this drive?
A: Confirm the complete catalog number, supply voltage, motor ratings, grounding, overcurrent protection, and cabinet ventilation. Installation and maintenance must be performed by qualified personnel. Isolate all power sources and follow the manufacturer’s DC bus discharge procedure before working on the equipment. After installation, verify the wiring and parameters, then test the motor control and regenerative braking functions under controlled conditions before returning the system to service.
Allen Bradley 20P41AB055RA0NNN PowerFlex DC Drives is in stock. Please contact us for a quick quote and competitive pricing.
