Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | 20P41AD167RA0NNN |
| Product Type | PowerFlex DC Drive |
| Product Series | PowerFlex DC |
| Drive Type | Regenerative DC Drive |
| Input Voltage | 480 V AC |
| Nominal AC Voltage | 460 V AC |
| Input Phase | 3-phase |
| Input Type | 6-pulse |
| Input Frequency | 50/60 Hz |
| Rated DC Output Current | 167 A |
| Rated Motor Power | 100 HP / 75 kW |
| Motor Operation | Four-quadrant regenerative operation |
| Field Supply | Single-phase regulated |
| Feedback Options | DC tachometer and encoder |
| Enclosure Rating | IP20 |
| Enclosure Type | NEMA/UL Type Open, with conformal coating |
| Frame Size | B |
| Human Interface Module (HIM) | Not included; blank plate supplied |
| Communication Module | Not included |
| Documentation | User manual |
| Installation | Industrial control cabinet |
| Lifecycle Status | Scheduled for discontinuation on April 15, 2027 |
| Dimensions | 311 × 388 × 350 mm |
| Weight | 25.5 kg |
FAQ
1. What is the Allen-Bradley 20P41AD167RA0NNN used for?
The 20P41AD167RA0NNN is a regenerative PowerFlex DC drive designed to control the speed and torque of industrial DC motors. It is suitable for applications that require precise speed regulation, controlled acceleration and deceleration, reversing, and regenerative braking, such as conveyors, winding systems, and heavy-duty processing machinery.
2. What are the input power requirements for this drive?
This drive uses a three-phase AC supply rated at 480 V, with a nominal operating voltage of 460 V AC. It has a six-pulse input configuration. Before installation, verify the supply voltage, frequency, grounding, and circuit protection requirements against the manufacturer’s documentation.
3. What are the rated output current and motor power?
The drive is rated for a DC output current of 167 A and a motor power of 100 HP (approximately 75 kW). The connected motor’s armature voltage, current, field requirements, and duty cycle must be compatible with the drive. Check the motor nameplate and application requirements before commissioning.
4. What is the advantage of four-quadrant regenerative operation?
Four-quadrant operation supports forward and reverse motoring as well as regenerative braking in both directions. Under suitable operating conditions, braking energy can be returned to the AC supply. This capability is useful for applications with high-inertia loads, frequent reversing, or repeated acceleration and deceleration.
5. Does the 20P41AD167RA0NNN include a Human Interface Module or communication module?
No. This configuration is supplied without a Human Interface Module (HIM) or communication module. A blank plate is fitted in place of the HIM. Confirm the required operator interface and communication accessories before integrating the drive into the control system.
6. Which feedback devices are supported by this drive?
The PowerFlex DC platform supports DC tachometer and encoder feedback. The appropriate feedback method depends on the motor configuration and required speed-control accuracy. Check device compatibility, signal wiring, and feedback parameter settings before starting the motor.
7. What should be checked before commissioning the drive?
Verify the incoming AC supply, motor armature and field connections, grounding, circuit protection, control wiring, and cabinet ventilation. Confirm that motor ratings, feedback settings, current limits, and control parameters match the application. Follow the manufacturer’s installation instructions and apply appropriate lockout/tagout procedures during maintenance.
8. How can common operating faults be diagnosed?
Begin by checking the drive’s fault codes and status indicators. Inspect the incoming power supply, motor connections, field circuit, feedback signals, control commands, and mechanical load. Review motor parameters and current-limit settings before making adjustments. Always isolate the power supply and verify a safe condition before inspecting wiring or replacing components.
