Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 6300M-150BAPSXDN1S |
| Manufacturer | Allen-Bradley |
| Product Series | ASEM 6300M |
| Product Type | Industrial Panel Monitor |
| Screen Size | 15 inches |
| Display Aspect Ratio | 4:3 |
| Display Resolution | 1024 × 768 pixels (XGA) |
| Touchscreen Type | Single-touch resistive touchscreen |
| Bezel Material | Aluminum |
| Mounting Type | Panel mount |
| Power Supply | 24 V DC, isolated |
| Video Interface | Verify supported video connections against the product documentation |
| Operating System | No built-in operating system; requires a compatible external computer or controller |
| Typical Applications | HMI visualization, machine monitoring, process data display and operator interfaces |
| Weight | 1 kg |
| Product Status | Discontinued as of June 1, 2025 |
| Replacement Model | 6300M-YW0A15EAAS |
FAQ
1. What is the main function of the Allen-Bradley 6300M-150BAPSXDN1S industrial monitor?
The 6300M-150BAPSXDN1S belongs to the ASEM 6300M series of industrial monitors. It displays operating information generated by an industrial computer, thin client or other compatible video source. Typical applications include HMI screens, machine status displays, process data, alarm messages and operator interfaces. The monitor primarily handles visual output and touch input; it does not independently execute PLC control logic or HMI software. A compatible host system is required to generate the displayed content.
2. What display resolution does the 6300M-150BAPSXDN1S support?
This model uses a 4:3 display format with a resolution of 1024 × 768 pixels, commonly referred to as XGA. This resolution is suitable for traditional industrial HMI applications, including process graphics, equipment status screens, alarm lists and operator menus. When connecting the monitor to an industrial computer, configure a supported display mode and check that the application layout fits the available screen area. Incorrect resolution settings can cause distorted images, misplaced interface elements or incomplete screen content.
3. What type of touchscreen does this monitor use?
The 6300M-150BAPSXDN1S features a standard single-touch resistive touchscreen. It allows operators to select buttons, navigate menus and interact with graphical control screens through individual touch inputs. Touch functionality depends on the host computer, supported interface connections and appropriate driver configuration. During commissioning, test the active screen area and confirm that touch coordinates correspond correctly to the displayed controls. If touch input is inaccurate or unavailable, check the driver, connection and calibration settings before assuming a hardware failure.
4. What power supply is required for the 6300M-150BAPSXDN1S?
The specified power configuration is isolated 24 V DC. Use a suitable DC power supply that meets the manufacturer’s electrical requirements, and verify polarity and terminal assignments before energizing the monitor. Inspect the wiring and grounding arrangements as part of the installation process. If the monitor fails to start, check that the supply voltage is present and stable before investigating the video signal or touchscreen connection. Do not connect a different voltage source without confirming that it is supported by the exact model.
5. Can the 6300M-150BAPSXDN1S connect directly to a PLC?
The monitor is primarily a display device and does not replace a PLC or industrial computer. In a typical installation, a compatible computer or visualization controller runs the HMI software and sends the video signal to the monitor. The PLC exchanges process data with the host running the HMI application, while the monitor displays that information and receives operator touch input through the supported host interface. Before integration, verify video output compatibility, touchscreen connectivity and driver support for the existing automation system.
6. What should be checked if the monitor displays a blank screen?
Start by checking the isolated 24 V DC supply and confirming that the monitor is receiving power correctly. Next, inspect the video cable, connectors and host computer’s display output. Verify that the selected connection matches the monitor’s supported input and that the computer is producing a compatible resolution. If the screen remains blank, test the monitor with a known-compatible video source and inspect the cables for damage or loose connections. If these checks do not resolve the problem, consult the product documentation for further troubleshooting.
7. What should be considered when installing the monitor in an industrial control panel?
The monitor uses an aluminum bezel and is designed for panel mounting. Before installation, consult the manufacturer’s mechanical drawing to confirm the panel cutout, mounting clearance, fastening method and sealing requirements. Ensure that the panel can support the monitor securely and that the installation provides appropriate heat dissipation. Route power and signal cables to minimize mechanical stress and electrical interference. After mounting, verify that the display operates correctly, touchscreen responses are accurate and all connections remain secure during operation.
8. Is the Allen-Bradley 6300M-150BAPSXDN1S discontinued, and what should be checked before replacement?
This model was discontinued effective June 1, 2025, and the listed direct replacement is 6300M-YW0A15EAAS. Before purchasing a replacement, compare the 15-inch screen size, 1024 × 768 resolution, aluminum bezel, single-touch operation, panel-mount configuration and isolated 24 V DC power requirement. Also verify video connections, touchscreen compatibility and support for the existing industrial computer. A replacement that fits the panel may still differ in electrical or functional characteristics, so test the display, touch operation and system integration before returning the equipment to service.
Allen Bradley 6300M-150BAPSXDN1S ASEM 6300M Monitor is in stock. Please contact us for a quick quote and competitive pricing.
