Allen Bradley MPL-A1520U-HJ72AA Servo Motor
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | MPL-A1520U-HJ72AA |
| Product Type | Low-Inertia Brushless AC Servo Motor |
| Product Series | MP-Series MPL |
| Voltage Class | 200 V AC |
| Rated Voltage | 230 V AC |
| Rated Power | 0.27 kW |
| Rated Speed | 7000 rpm |
| Continuous Stall Torque | 0.49 Nm |
| Peak Stall Torque | 1.58 Nm |
| Continuous Stall Current | 1.8 A |
| Peak Stall Current | 6.1 A |
| Frame Size | 63 mm |
| Magnet Stack Length | 50.8 mm |
| Feedback Type | Incremental Encoder |
| Feedback Resolution | 2000 pulses/revolution |
| Shaft Type | Keyed Shaft Extension |
| Connector Type | SpeedTEC DIN Connector |
| Connector Orientation | Right-Angle, 180° Rotatable |
| Brake | No Brake |
| Mounting Type | IEC Metric Flange, Free Mounting Holes |
| Shaft Seal | Not Included |
| Operating Temperature | 0–40°C |
| Weight | 1.2 kg |
| Product Status | Discontinued |
FAQ
1. What are the main applications of the MPL-A1520U-HJ72AA servo motor?
The Allen-Bradley MPL-A1520U-HJ72AA is designed for industrial motion-control applications requiring precise speed regulation and responsive acceleration. Typical applications include automated assembly equipment, packaging machinery, material handling systems, and production lines. Its low-inertia design supports frequent starts, stops, and changes in motion.
2. Which servo drives are compatible with the MPL-A1520U-HJ72AA?
This motor requires a compatible 200 V-class servo drive that supports its electrical ratings and incremental encoder feedback. Compatibility should be checked against the complete motor catalog number, drive current capacity, feedback interface, and application requirements. Confirm the manufacturer’s compatibility documentation before replacing or selecting a drive.
3. How does the incremental encoder support motion control?
The incremental encoder generates position pulses as the motor shaft rotates. The servo drive uses these signals to monitor movement and regulate motor speed and position through closed-loop control. Correct encoder wiring, signal configuration, and drive tuning are important for maintaining accurate and stable operation.
4. Does the MPL-A1520U-HJ72AA have an integrated holding brake?
No. This model does not include an integrated holding brake. If the application requires a load to remain stationary after power is removed, an appropriately rated external holding mechanism may be required. For vertical axes or gravity-loaded machinery, assess the risk of uncontrolled movement and implement suitable safety measures.
5. What are the motor’s rated speed and torque capabilities?
The motor has a rated speed of 7000 rpm, a continuous stall torque of 0.49 Nm, and a peak stall torque of 1.58 Nm. Actual operating performance depends on the load, drive configuration, acceleration profile, and thermal conditions. The continuous and peak ratings should be considered separately when designing the motion-control system.
6. What should be checked when installing this servo motor?
Verify the motor and drive compatibility, supply voltage, grounding, power connections, encoder wiring, and mechanical alignment. Ensure the mounting surface is secure and the coupling is suitable for the keyed shaft. Before enabling the drive, check that the driven mechanism moves freely and that all required machine safety measures are in place.
7. Why might the motor experience positioning errors or unstable operation?
Potential causes include incorrect encoder wiring, electrical interference, unsuitable servo tuning, excessive load inertia, loose mechanical couplings, or incorrect drive parameters. Mechanical backlash and poor shaft alignment can also affect positioning accuracy. Check the drive’s diagnostic information and inspect both electrical connections and mechanical components before making adjustments.
8. Is the MPL-A1520U-HJ72AA still available, and what should be considered when replacing it?
The MPL-A1520U-HJ72AA has been discontinued by Rockwell Automation. When sourcing a replacement, verify the motor’s voltage class, speed and torque requirements, encoder type, shaft configuration, connector orientation, mounting arrangement, and brake requirements. The MPL-A1520U-EJ72AA is listed as a replacement option by the manufacturer, but its single-turn high-resolution absolute encoder differs from the HJ72AA’s incremental encoder. Confirm drive compatibility and system requirements before substitution.
Allen Bradley MPL-A1520U-HJ72AA Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
