Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | MPL-A230P-EJ74AA |
| Manufacturer | Rockwell Automation |
| Product Type | Low-Inertia AC Servo Motor |
| Product Series | MP-Series MPL |
| Voltage Rating | 230 V AC |
| Voltage Class | 200 V AC |
| Frame Size | 75 mm |
| Magnet Stack Length | 76.2 mm |
| Rated Speed | 5000 rpm |
| Maximum Speed | 5000 rpm |
| Continuous Rated Power | 0.86 kW |
| Continuous Stall Torque | 2.1 Nm |
| Peak Torque | 8.2 Nm |
| Feedback Type | Single-Turn High-Resolution Absolute Encoder |
| Feedback Protocol | Hiperface |
| Feedback Resolution | Sin/Cos, 128 cycles/revolution |
| Shaft Type | Keyed Shaft Extension |
| Holding Brake | 24 V DC Brake |
| Connector Type | Right-Angle SpeedTec DIN Connector |
| Connector Orientation | Rotatable 180° |
| Mounting Type | IEC Metric Flange Mount |
| Mounting Holes | Free Mounting Holes, Type FF |
| Shaft Seal | No |
| Rotor Inertia | 8.2 × 10⁻⁵ kg·m² |
| Protection Rating | IP50 |
| Operating Temperature | 0–40°C |
| Weight | 2.6 kg |
FAQ
1. What applications is the Allen-Bradley MPL-A230P-EJ74AA servo motor suitable for?
The Allen-Bradley MPL-A230P-EJ74AA is a low-inertia servo motor designed for industrial motion-control applications that require accurate positioning and responsive speed control. Typical applications include automated assembly equipment, packaging machinery, material handling systems, and production lines. Selection should be based on the required torque, acceleration, duty cycle, and compatibility with the servo drive.
2. Which servo drives are compatible with the MPL-A230P-EJ74AA?
Compatibility depends on the exact servo drive model, voltage class, feedback interface, and motor configuration. The MPL-A230P-EJ74AA belongs to the Allen-Bradley MP-Series MPL family, but compatibility should be verified against the drive manufacturer’s documentation before installation. Confirm that the drive supports the motor’s encoder and brake configuration, where applicable.
3. What is the function of the motor’s absolute encoder?
The motor uses a high-resolution, single-turn absolute encoder to provide rotor position feedback to the servo drive. This feedback supports closed-loop control of position, speed, and torque. The Hiperface interface and Sin/Cos signals enable the drive to monitor motor movement. Correct feedback wiring and compatible drive settings are essential for stable operation.
4. What is the purpose of the integrated 24 V DC holding brake?
The holding brake helps prevent the motor shaft from rotating when the brake is engaged, particularly when the motor is stationary. It can be useful in applications where an axis must maintain its position during a stop. The brake should not be assumed suitable for routine dynamic stopping unless the manufacturer explicitly permits that use. Follow the specified brake wiring and control sequence.
5. What should be checked before commissioning the MPL-A230P-EJ74AA?
Verify the motor catalog number, servo drive compatibility, power supply requirements, feedback connections, brake wiring, grounding, and mechanical coupling. Check that the motor is securely mounted and that the driven load moves freely. Configure the drive using the correct motor parameters, then conduct initial tests at low speed and with suitable safety measures before operating the machine under normal load.
6. What can cause a servo drive fault when operating this motor?
Common causes include incorrect encoder wiring, loose connectors, power supply abnormalities, excessive mechanical load, incorrect motor parameters, or brake-control problems. Start by recording the drive alarm code and checking the relevant diagnostic information. Inspect power and feedback connections, verify the brake release sequence, and compare the configured parameters with the motor nameplate and technical documentation.
7. How can positioning errors or unstable motion be troubleshot?
Check the encoder feedback signal, cable condition, mechanical coupling, load alignment, and servo drive alarm history. Incorrect tuning, mechanical backlash, vibration, or sudden load changes can affect positioning accuracy. Confirm that the configured motor data is correct and follow the drive manufacturer’s tuning procedure. If the issue continues, isolate mechanical and electrical causes before determining whether the motor needs repair or replacement.
8. What should be considered when replacing an MPL-A230P-EJ74AA servo motor?
Confirm that the replacement matches the required electrical ratings, torque and speed performance, encoder interface, keyed shaft, connector arrangement, and holding-brake configuration. Check compatibility with the existing servo drive and control system, including feedback wiring and parameter settings. Do not assume that another motor in the same series is a direct substitute without verifying the complete catalog number and applicable technical documentation.
Allen Bradley MPL-A230P-EJ74AA Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
