Bently 330850-90-05 3300 XL 25mm Front Sensor
Product Overview
The Bently Nevada 330850-90-05 is a 3300 XL 25mm Front Mount Proximity Sensor, part of the widely used Bently 3300 XL series. This sensor is designed to monitor the static and dynamic displacement of machine shafts and other components with high accuracy. It works in combination with matching extension cables and Proximitor sensors to form a complete eddy current proximity measurement system.
This particular model is suitable for large shaft applications, including steam, gas, and hydro turbines, and large motors and compressors. The 25mm tip allows for an extended linear range, providing accurate, non-contact displacement measurements over a greater distance than smaller sensors.
Key Features
-
25mm Tip Design: Ideal for large shaft and wide-gap measurement applications.
-
Non-Contact Measurement: Provides accurate displacement readings without physical contact.
-
System Compatibility: Works with Bently Nevada 3300 XL extension cables and Proximitor sensors.
-
Extended Linear Range: Offers a broader measurement window compared to smaller sensors.
-
Rugged Construction: Designed to endure harsh industrial environments.
-
Improved Reliability: Part of the 3300 XL series known for robust performance and long service life.
-
Agency Certifications: Meets global standards for safety and performance.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | Length:9.0metres |
| Weight | 0.55 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | 330850-90-05 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Sensor Type | Eddy Current Proximity Probe |
| Tip Diameter | 25 mm |
| Mounting Thread | 3/4-16 UNF |
| Sensing Range | Up to 12 mm linear range |
| Material | Stainless steel housing |
3.3 Electrical and Environmental Ratings
| Item | Specification |
|---|---|
| Operating Temperature | −35°C to +177°C |
| Frequency Response | DC to 10 kHz |
| Sensitivity | Nominal 7.87 mV/μm (200 mV/mil) |
| Vibration Tolerance | 20 g, 10–2,000 Hz |
| Shock Survival | 1000 g, 1 ms |
| Environmental Rating | IP65 or better (with proper installation) |
| EMC Compliance | EN 61000 Series |
Industry Applications
-
Power Generation: Shaft position and vibration monitoring for steam and gas turbines.
-
Oil & Gas: Non-contact monitoring in compressors and large pumps.
-
Petrochemical Processing: Suitable for harsh environments with high temperatures and contaminants.
-
Heavy Industry: Used in large motor and generator condition monitoring.
-
Water Treatment: Monitors critical rotating assets in pumping systems.
-
Marine & Offshore: Durable sensor choice for engine and propulsion systems.
The Bently 330850-90-05 3300 XL 25mm Front Sensor offers high-precision, reliable shaft displacement measurements for large-scale rotating equipment. Its rugged design and extended range make it an essential component for demanding industrial vibration and position monitoring applications.
Bently 330850-90-05 3300 XL 25mm Front Sensor is in stock. Please contact us for a quick quote and competitive pricing.
