Product Overview
The Bently Nevada 3500/42M is a four-channel Proximitor / Seismic Monitor designed for use in the Bently Nevada 3500 Machinery Protection System. It provides continuous monitoring and protection for critical rotating machinery by measuring and analyzing vibration, displacement, and position signals from proximity probes, velocity sensors, or accelerometers.
This module is a key component in turbine, compressor, pump, and generator protection systems, providing both machinery protection and condition monitoring functions. It accepts dynamic and static signals, processes them internally, and compares the results to user-defined alert and danger setpoints. When limits are exceeded, the module activates alarm and relay outputs to initiate corrective or shutdown actions.
The 3500/42M improves upon earlier versions with higher channel density, enhanced signal conditioning, and flexible configuration capabilities. Each channel pair can be configured for a specific function, allowing two independent monitoring functions per module.
Key Features
-
Four-channel monitor configurable for Proximitor or seismic sensor inputs.
-
Supports radial vibration, axial position, differential expansion, and casing vibration measurements.
-
Independent configuration for each pair of channels.
-
Real-time signal conditioning, alarm processing, and system protection logic.
-
Compatible with Bently Nevada 3500 racks and system communications.
-
Compact, rack-mounted design for efficient cabinet utilization.
-
High reliability and continuous self-diagnostic capability.
Technical Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model Number | 3500/42M | Four-channel Proximitor / Seismic Monitor |
| Part Numbers | 176449-02 (Front Module) + 135489-01 (I/O Module) | Front processing module with corresponding rear I/O interface |
| Number of Channels | 4 (configured in two pairs) | Each pair independently programmable |
| Sensor Inputs | Proximity probes, velocity transducers, or accelerometers | Compatible with Bently Nevada sensors |
| Measurement Functions | Radial vibration, axial position, thrust, eccentricity, acceleration, velocity | Configurable per channel |
| Power Consumption | Approximately 7.7 W typical | Standard I/O configuration |
| Input Impedance | 10 kΩ nominal | High-accuracy signal conditioning |
| Sensitivity | 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil) | Depends on sensor and configuration |
| Frequency Response | Direct filter: 4 Hz – 4,000 Hz or 1 Hz – 600 Hz; Gap filter: 0.09 Hz (−3 dB) | For vibration and position signals |
| Alert and Danger Setpoints | User-programmable per channel | Independently adjustable alarm levels |
| Rack Slots Required | 1 full-height front slot and 1 full-height rear slot | Fits standard 3500 rack architecture |
| Operating Temperature Range | −30 °C to +65 °C (−22 °F to +149 °F) | Suitable for industrial environments |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to +185 °F) | Safe for transport and storage |
| Humidity Range | Up to 95% non-condensing | Industrial environmental tolerance |
| Dimensions (H × W × D) | 241.3 mm × 24.4 mm × 163.1 mm (9.50 in × 0.96 in × 6.42 in) | Compact rack-mount format |
| Weight | Approx. 0.46 kg (1.01 lb) | Lightweight for easy handling |
| Material | Aluminum alloy chassis | Provides strength and EMC protection |
| Mounting Type | Plug-in rack installation | Quick removal and replacement |
| Compliance | CE, CSA, ATEX, IECEx (depending on variant) | Certified for global use |
| Country of Origin | United States (Minden, Nevada, USA) | Manufactured by Bently Nevada, Baker Hughes |
