Bently Nevada 330102-00-13-15-02-05 Eddy Current Proximity Probe Assembly
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 330102-00-13-15-02-05 |
| Product Type | Eddy Current Proximity Probe Assembly |
| Probe Tip Diameter | 5 mm |
| Probe Length | 130 mm |
| Extension Cable Length | 15 m |
| Total System Length | 13 m |
| Calibration Standard | API 670 |
| Sensitivity | 7.87 mV/µm (nominal) |
| Linear Range | 2.0 mm |
| Frequency Response | 0–10 kHz |
| Output Signal | Analog displacement voltage signal |
| Supply Requirements | ±24 VDC (via compatible driver) |
| Connector Style | Industrial threaded coaxial connector |
| Material | Stainless-steel probe body; shielded coaxial cable |
| Dimensions (Probe Body) | 130 × 8 × 8 mm |
| Weight | Approx. 0.29 kg (probe + cable assembly) |
| Operating Temperature | −35°C to +100°C |
| Environmental Protection | IP67 |
| Installation Method | Threaded mount for precise mechanical positioning |
| Recommended Applications | Shaft vibration, radial displacement, and thrust position monitoring |
FAQ
-
Q1: What distinguishes the 330102-00-13-15-02-05 model from similar variants?
A1: This version includes a 15 m extension cable and a factory-matched configuration optimized for stable displacement monitoring. -
Q2: Is this probe assembly compatible with standard proximity drivers?
A2: Yes. It is designed to operate with drivers calibrated to a 7.87 mV/µm sensitivity. -
Q3: Can the probe handle continuous operation in oil-lubricated machinery?
A3: The sealed IP67-rated structure makes it suitable for environments where oil exposure is common. -
Q4: How does the longer extension cable affect system accuracy?
A4: The probe, cable, and driver are produced as a matched set, ensuring consistent performance despite cable length. -
Q5: What precautions should be followed during installation?
A5: Maintain the recommended initial gap and ensure the threaded mount is properly aligned to avoid signal distortion. -
Q6: What type of machine conditions is this model best suited for?
A6: It is frequently used for monitoring dynamic shaft behavior in turbines, compressors, pumps, and large rotating equipment. -
Q7: Does the probe require periodic calibration?
A7: Routine recalibration is generally unnecessary; however, system-level checks during scheduled maintenance are recommended. -
Q8: How should the cable be routed to ensure optimal performance?
A8: Keep the cable away from high-power electrical lines and sharp bends to preserve signal quality and system longevity.
Bently Nevada 330102-00-13-15-02-05 Eddy Current Proximity Probe Assembly is in stock. Please contact us for a quick quote and competitive pricing.
