Product Overview
The Bently Nevada 330780-90-CN is a high-performance Proximitor Sensor from the 3300 XL 11 mm series, designed to provide precise, non-contact measurement of shaft vibration and position in rotating machinery.
This model features a 9.0 meter total system length, making it suitable for installations where the proximity probe must be located further from the monitoring system.
The “CN” designation indicates the China-specific configuration, optimized for compliance with regional installation standards while maintaining the same electrical and mechanical performance as other 330780-90 models.
Fully compliant with API 670 standards, the 330780-90-CN is widely used in turbines, compressors, motors, and pumps for critical vibration and displacement monitoring.
Key Features
-
11 mm proximity system for accurate shaft vibration and displacement measurement
-
Total system length of 9.0 m (probe + extension cable + Proximitor)
-
Non-contact eddy-current measurement principle
-
Linear and repeatable output over wide operating ranges
-
Compatible with 3500 and 1900 series monitoring systems
-
Excellent EMI and RFI immunity for harsh industrial environments
-
Fully compliant with API 670 machinery protection requirements
Technical Specifications
| Parameter | Specification | Description / Notes |
|---|---|---|
| Model Number | 330780-90-CN | Proximitor Sensor, China configuration |
| Manufacturer | Bently Nevada (GE Measurement & Control) | — |
| Measurement Type | Non-contact displacement and vibration | Eddy-current principle |
| Compatible Probe | 11 mm 3300 XL proximity probe | Matched set required |
| System Length | 9.0 m (29.5 ft) | Total probe + cable + Proximitor length |
| Mounting Type | DIN Rail | Compact, easy installation |
| Output Sensitivity | 3.94 V/mm (100 mV/mil) | Standard calibration |
| Linear Range | 0 to 2.3 mm (0 to 90 mils) | Full linear range |
| Output Voltage Range | –10 V DC to –2 V DC | Proportional to probe gap |
| Frequency Response | DC to 10 kHz | For dynamic and static signals |
| Power Supply Voltage | –23 V DC to –25 V DC | Nominal operation |
| Accuracy | ±0.5 % of Full Scale | Within calibrated range |
| Operating Temperature (Electronics) | –35 °C to +100 °C | Continuous operation |
| Probe Operating Temperature | –35 °C to +177 °C | Extended temperature range |
| Storage Temperature | –55 °C to +85 °C | Non-operational condition |
| Relative Humidity | 5 % – 95 % (non-condensing) | Industrial environments |
| Recommended Target Size | ≥ 30.5 mm flat surface | Ensures calibration accuracy |
| Electrical Isolation | Input / Output isolated | Reduces interference |
| Housing Material | Aluminum alloy (A380) | Corrosion-resistant housing |
| Compliance Standards | API 670, CE, CSA | Industrial standard compliance |
| Dimensions (H × W × D) | 103 mm × 75 mm × 52 mm (4.06 × 2.95 × 2.05 in)** | Standard proximitor enclosure |
| Weight | Approx. 0.82 kg (1.81 lb) | Typical module weight |
Bently Nevada 330780-90-CN Proximitor / Proximity Sensor Module is in stock. Please contact us for a quick quote and competitive pricing.
