Bently Nevada 330851-04-000-040-10-01-00 Proximity Probe – 3300 XL Series
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Bently Nevada |
| Product Type | Proximity Probe |
| Product Model | 330851-04-000-040-10-01-00 |
| Product Series | 3300 XL Series |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Measurement Principle | Eddy-current non-contact displacement measurement |
| Nominal Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Probe Case Material | Stainless steel |
| Sensing Target | Conductive metallic shaft or target surface |
| Measurement Application | Radial vibration and axial position monitoring |
| Probe Length | 40 mm nominal |
| Connector | Miniature coaxial connector |
| Operating Temperature | Approximately −52 to +177°C |
| Extension Cable | Requires compatible 3300 XL extension cable |
| Proximitor Compatibility | 3300 XL Proximitor Sensor |
| Dimensions (L × W × H) | Approx. 40 × 8 × 8 mm probe body; overall assembly length depends on configuration |
| Weight | Approx. 0.05 kg |
| Battery | No |
| Magnet | No |
FAQ
Q: What is the Bently Nevada 330851-04-000-040-10-01-00?
A: It is a 3300 XL 8 mm proximity probe designed for non-contact measurement of shaft displacement, vibration, and position in rotating machinery.
Q: What measurement principle does this probe use?
A: The probe uses eddy-current technology. It generates a high-frequency electromagnetic field and detects changes caused by the distance between the probe tip and a conductive metallic target.
Q: What is the nominal probe diameter?
A: The probe has a nominal 8 mm diameter, which is the standard sensing diameter for the Bently Nevada 3300 XL 8 mm proximity transducer family.
Q: What is the probe used to monitor?
A: Typical applications include radial shaft vibration, shaft position, axial displacement, and other dynamic measurements on turbines, compressors, pumps, motors, generators, and similar rotating equipment.
Q: Does the probe work by itself?
A: No. The probe forms part of a complete proximity transducer system. It is normally connected through a compatible extension cable to a 3300 XL Proximitor Sensor, which supplies the probe and conditions its signal.
Q: What is the significance of the 40 mm designation in the model number?
A: The 040 portion identifies the specified probe configuration with a nominal 40 mm length characteristic. Exact overall installed length also depends on the mechanical configuration and connector arrangement.
Q: What are the approximate dimensions and weight of the 330851-04-000-040-10-01-00?
A: The sensing probe body is approximately 40 mm long with an 8 mm nominal diameter. The probe assembly weighs roughly 0.05 kg; the complete probe, extension cable, and connector assembly will be heavier.
Q: Does the 330851-04-000-040-10-01-00 contain a battery or magnet?
A: No. It is a passive eddy-current proximity probe and does not contain a battery or permanent magnet. The electromagnetic field used for measurement is generated by the associated Proximitor Sensor.
Bently Nevada 330851-04-000-040-10-01-00 Proximity Probe – 3300 XL Series is in stock. Please contact us for a quick quote and competitive pricing.
