Bently Nevada 3500/22 146031-02 Transient Data Interface Module
Product Overview
The Bently Nevada 3500/22 146031-02 Transient Data Interface (TDI) is the core communications module in the 3500 Machinery Protection System. It serves as the primary interface between the 3500 rack and plant-wide monitoring software. The TDI collects static, dynamic, and status data from all modules within the rack and transmits this information to System 1 software via Ethernet. This model provides improved performance, higher communication reliability, and enhanced diagnostics capabilities compared with earlier revisions, ensuring robust machinery protection and condition monitoring in demanding industrial environments.
_
Main Features
Centralized data integration for all rack modules into a single communication channel
Dual Ethernet ports for redundant and secure data communication
Support for Modbus TCP and Modbus Serial protocols for seamless integration with DCS and SCADA systems
Hot-swappable design allowing module replacement without rack power-down
Advanced self-diagnostics for continuous monitoring of system health
High-speed data transfer for transient and static data to System 1 software
Designed for reliability in harsh industrial operating conditions
_
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.91 kg |
| _ |
General Information
| Item | Specification |
|---|---|
| Manufacturer | Bently Nevada (GE Measurement & Control) |
| Model Number | 3500/22 146031-02 |
| Product Type | Transient Data Interface (TDI) |
| Mounting | Installed in 3500 rack slot |
| Operating Temp. | 0°C to +60°C |
| Storage Temp. | -40°C to +85°C |
| _ |
Electrical Characteristics
| Item | Specification |
|---|---|
| Communication Ports | Dual Ethernet 10/100Base-T |
| Supported Protocols | TCP/IP, Modbus TCP, Modbus Serial |
| Power Supply | Supplied from 3500 rack backplane |
| Data Handling | Static, dynamic, and event data collection |
| Firmware Revision | 146031-02 |
| _ |
Environmental Specifications
| Item | Specification |
|---|---|
| Humidity Range | 5–95% RH (non-condensing) |
| Vibration | 5–2000 Hz, 0.7 g |
| Shock Resistance | 30 g, 11 ms half-sine |
| Protection Class | IP20 (when installed in rack) |
| _ |
Industry Applications
The Bently Nevada 3500/22 146031-02 is widely applied in:
Oil & Gas: Real-time monitoring of compressors, turbines, and pumps
Power Generation: Condition monitoring of steam turbines, gas turbines, and generators
Petrochemical and Refining: Continuous protection of critical rotating machinery
Metals and Mining: Surveillance of high-speed, heavy-duty rotating assets
Pulp & Paper: Protection of refiners, drives, and auxiliary equipment
Bently Nevada 3500/22 146031-02 Transient Data Interface Module is in stock. Please contact us for a quick quote and competitive pricing.
