Product Overview
The 3500/54M (model 286566-01) is a high-integrity overspeed detection module designed for protection of critical rotating machinery. It accepts shaft speed signals (from proximity probes or magnetic pickups), compares the measured speed against configured thresholds and can initiate alarm or trip actions when speed limits are exceeded.
Designed for use in a 3500-series rack system with redundant power supplies and voting logic architectures (e.g., 2-out-of-2 or 2-out-of-3) for enhanced reliability.
Key Features
-
Accepts standard proximity probe or magnetic pickup speed signals.
-
Configurable full-scale speed range (e.g., to 99,999 rpm).
-
Fast response to overspeed conditions, suitable for high-risk machinery.
-
Supports redundant system architectures for high availability protection.
-
Rugged industrial design for harsh ambient conditions.
-
Fully compatible with 3500/54M rack environment and associated I/O modules.
Technical Specifications
| Parameter | Specification | Description / Notes |
|---|---|---|
| Model / Catalog Number | 286566-01 | Overspeed Detection Module for 3500/54M series |
| Series | 3500/54M | Machinery protection modular rack system |
| Input Signal Type | Proximity probe or magnetic pickup | Standard speed sensing devices |
| Input Signal Range | +10.0 V to –24.0 V | Accepts standard sensor output ranges |
| Input Impedance | Approx. 20 kΩ | Typical value |
| Full-Scale Speed Range | Up to 99,999 rpm | Programmable maximum |
| Power Consumption | Approx. 8.0 W | Typical operating power |
| Operating Temperature Range | –30 °C to +65 °C | Ambient operating environmental range |
| Storage Temperature Range | –40 °C to +85 °C | Non-operating / storage condition |
| Humidity | Up to 95% non-condensing | Industrial environmental tolerance |
| Dimensions (H × W × D) | Approx. 241.3 mm × 24.4 mm × 241.8 mm | Standard full-height 3500-series module size |
| Weight | Approx. 0.8 kg | Typical module net weight |
| Compliance | API 670 & API 612 | Meets major overspeed protection standards |
Bently Nevada 3500/54M 286566-01 Overspeed Detection Module is in stock. Please contact us for a quick quote and competitive pricing.
