Product Overview
The Bently Nevada 3500/70M (176449-09) is a Reciprocating Compressor Monitor Module used within the Bently Nevada 3500 Machinery Protection System.
It provides continuous protection and condition monitoring for reciprocating compressors, detecting critical mechanical conditions such as rod drop, frame velocity, crosshead acceleration, and impact events.
This module is designed for precise, real-time detection of machine wear and imbalance. It generates both Alert and Danger alarms when operating parameters exceed configured limits, helping prevent costly equipment failures and unscheduled downtime.
The 3500/70M meets API 670 requirements and integrates seamlessly with other Bently Nevada 3500 modules to form a complete protection and monitoring solution for reciprocating machinery in oil, gas, and power industries.
Key Features
-
Specialized for reciprocating compressor monitoring.
-
Supports up to four independently configurable input channels.
-
Measures rod drop, frame velocity, crosshead acceleration, and impact.
-
Provides real-time machinery protection and diagnostics.
-
Two programmable alarm levels (Alert and Danger) per channel.
-
Configurable through 3500 Configuration Software.
-
Optional 4–20 mA proportional outputs via I/O module.
-
LED indicators: OK, TX/RX, and Bypass for status monitoring.
-
High immunity to vibration, temperature, and electrical interference.
-
Compliant with API 670, CE, CSA, and ATEX standards.
Technical Specifications
| Parameter | Specification | Description / Notes |
|---|---|---|
| Model Number | 3500/70M | Reciprocating Compressor Monitor |
| Part Number | 176449-09 | Latest hardware revision |
| System Compatibility | Bently Nevada 3500 Machinery Protection System | Full-height module |
| Number of Channels | 4 | Each channel configurable |
| Measurement Types | Rod Drop, Crosshead Acceleration, Frame Velocity, Impact | Channel-specific configuration |
| Input Type | Proximity probes and accelerometers | Compatible with Bently Nevada sensors |
| Input Range | ±50 mils (rod drop), up to 100 g (acceleration) | Depending on sensor |
| Sampling Rate | Up to 20 kHz | High-speed data capture |
| Output Type | 4–20 mA proportional outputs (optional) | Available via matching I/O module |
| Alarm Levels | Two per channel (Alert, Danger) | User-programmable |
| Alarm Delay | 0–100 seconds | Configurable |
| Data Communication | Via 3500 Rack Backplane | Transmits to system display/relays |
| Signal Processing | Digital, continuous | Real-time analysis |
| Power Consumption | Approx. 10 W | Typical |
| Operating Temperature | –30 °C to +65 °C | Continuous operation |
| Storage Temperature | –40 °C to +85 °C | Non-operating condition |
| Relative Humidity | 5–95% non-condensing | Industrial-grade |
| Dimensions (H × W × D) | 241.3 × 24.4 × 241.8 mm (9.50″ × 0.96″ × 9.52″) | Full-height module |
| Weight | Approx. 0.9 kg (2.0 lb) | Typical |
| Mounting Type | Full-height slot installation | Via 3500 backplane |
| Certifications | API 670, CE, CSA, ATEX | Global compliance |
Bently Nevada 3500/70M 176449-09 Industrial Monitoring Module is in stock. Please contact us for a quick quote and competitive pricing.
