Bently Nevada 3500/72M 176449-08 Reciprocating Rod Position Monitor
Product Overview
The Bently Nevada 3500/72M 176449-08 Reciprocating Rod Position Monitor is an advanced monitoring solution designed to provide precise and real-time measurements of the rod position in reciprocating machinery. This module is crucial for ensuring the efficient operation and safety of reciprocating equipment, including compressors and pumps, by detecting misalignment, excessive wear, or operational anomalies. Integrated within the Bently Nevada 3500 Series monitoring system, it provides valuable insights for predictive maintenance and process optimization, minimizing unplanned downtime and maximizing asset life.
Key Features
-
Accurate Rod Position Monitoring: Ensures continuous, real-time monitoring of reciprocating rod positions for optimal machine performance.
-
High-Precision Sensors: Utilizes advanced sensors to provide accurate and reliable position data, enabling early detection of mechanical issues.
-
Predictive Maintenance Support: Helps identify potential faults and irregularities, enabling proactive maintenance strategies and reducing the risk of equipment failure.
-
Seamless Integration: Fully compatible with the Bently Nevada 3500 Series, facilitating easy integration and centralized monitoring.
-
Rugged and Reliable: Designed for harsh industrial environments, offering durability and long-term reliability in challenging conditions.
-
Simple Installation and Setup: Features flexible installation options with minimal downtime, allowing for quick system deployment.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | 3500/72M 176449-08 |
| Module Type | Reciprocating Rod Position Monitor |
| Mounting | DIN Rail Mountable |
| Communication Type | Digital Output (for system integration) |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24 V DC |
| Power Consumption | < 2 W |
| Operating Temp | -20°C to +70°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Bently Nevada 3500 Series |
| Communication Interface | Digital (for system integration) |
| Software Configuration | System 1, 3500 Monitoring Software |
Industry Applications
-
Reciprocating Machinery Monitoring: Perfect for monitoring the position of reciprocating rods in pumps, compressors, and engines, ensuring smooth and reliable operation.
-
Predictive Maintenance: A critical tool for predictive maintenance programs, offering data that helps to forecast failures and reduce the likelihood of unplanned downtime.
-
Oil & Gas: Widely used in the oil and gas industry to monitor reciprocating equipment like compressors, helping optimize performance and extend the life of assets.
-
Power Generation: Utilized in power plants to monitor reciprocating engines, compressors, and other machinery for optimal operation.
-
Chemical and Petrochemical: Provides valuable monitoring capabilities for reciprocating equipment in chemical and petrochemical plants, ensuring operational reliability and efficiency.
The Bently Nevada 3500/72M 176449-08 Reciprocating Rod Position Monitor is a key component for improving the reliability and efficiency of reciprocating machinery. With its advanced sensor technology and seamless integration into the Bently Nevada 3500 Series system, it provides accurate position data and supports predictive maintenance strategies. Designed for tough industrial environments, this monitor helps ensure the continuous operation of critical machinery, ultimately enhancing productivity and reducing downtime.
